Specifications
Nylon Fitler Mesh;Ceramic Filter PlateUsed for printing or filteration
Imported Machine from Switzerland
ISO9001;ISO14001
1Introduction
Nylon Filter Mesh; Ceramic Filter Plate for Air or Liquid as one of our mainly product we have imported weaving machines fom Switzerland and Italy with the skillful technology our products are very popular not only in China but also all over the world
2Application
It is widely used in filteration, textile printing and dyeing, printing plate, electronic printing, ceramics, glass printing,the industries of petroleum, chemical, metallurgy, cement, environmental dedusting and mine. The fabric has been brushed, so it is more flexible and thicker,the dedusting efficiency can reach 99.99%
3Specifications
1)Material: 100% nylon (polyester available if needed)
2)Weaving: Plain weave (Twill weave available if needed)
3)Mesh Count: 4T~140T mesh/cm(13mesh~355 mesh/inch)
4)Max. width: 365cm (143 inch)
5)Color: white/yellow/black
Monofilament or Doublefilament
We can provide products in special specifications according to your demand
4Designs
_drawstring
_wire ring
_flanged
_special designs
5Features & Advantages
1) Imported weaving and warping machines from Switerland or Italy make sure the high quality products and the production
2) We produce variouse of polyesters mesh, nylon mesh and some other stainless steel mesh for printing and filtering. Our products are widely applied in high-density printed circuit boards, CDs, keyboard, ceramics, printing of T-shirt textiles, printing on glasses, and adadvertisement signpost making etc.They also serve as filter in aerospace, petrifaction and other high technology regime
The following is the specifications
|
Specification (cm) |
Mesh Count (mesh/inch) |
Wire Dia. (um) |
Mesh opening (um) |
Open Area (%) |
Suggestion Highest Tension N/cm |
8T |
20 |
350 |
900 |
52 |
66 |
10 |
25 |
300 |
700 |
49 |
61 |
12 |
30 |
250 |
580 |
48 |
58 |
15 |
38 |
200 |
467 |
49 |
58 |
24 |
60 |
120 |
297 |
51 |
52 |
32 |
80 |
100 |
213 |
46 |
54 |
40 |
100 |
80 |
170 |
46 |
37 |
43 |
110 |
80 |
153 |
43 |
35 |
53 |
135 |
64 |
125 |
44 |
40 |
56 |
142 |
64 |
115 |
41 |
41 |
61 |
156 |
64 |
100 |
37 |
41 |
64 |
160 |
64 |
92 |
35 |
42 |
68 |
175 |
64 |
83 |
32 |
40 |
72 |
183 |
55 |
84 |
37 |
38 |
77 |
195 |
55 |
75 |
33 |
33 |
80 |
200 |
48 |
77 |
38 |
34 |
90 |
230 |
45 |
72 |
42 |
30 |
100 |
250 |
40 |
61 |
37 |
32 |
110 |
280 |
40 |
52 |
33 |
34 |
120 |
300 |
34 |
47 |
32 |
34 |
140 |
350 |
34 |
37 |
24 |
33 |
150 |
380 |
31 |
34 |
26 |
31 |
165 |
420 |
31 |
25 |
17 |
31 |
