Specifications
Air Filter Cartridge; Cylinder CartridgeMaterial:304,304L,316,316L
Mesh:1-635mesh
Wire:2.03-0.0203mm
ISO 9001 ISO 14001
Air Filter Cartridge; Cylinder Cartridge
Introducton
Stainless Steel Air Filter Cartridge; Cylinder Cartridge,wire mesh,stainless steel wire cloth
(stainless steel wire mesh,wire mesh,stainless steel wire cloth,stainless steel printed mesh,printed wiring board,stainless steel mesh)
Our products adopt high-quality stainless steel threads and alloy threads to weave.
Application
They are applied to a wide range of industries, such as printing, mining, petroleum, machine building, chemical, rubber, plastics, food ,pharmacy and cloth for radiation proof etc.
Features:
1) Materials: Different stainless steel materials: 302, 304, 316, 304L, 316L, 310, 310S,314 (Special materials: nickel thread, titanium thread, and tungsten are available if needed)
2) Weaving forms: plain weaving, twill weaving, microgroove-plain weaving-twill weaving, satin weaving, formatted with a lot of burs
3) Performance: stainless steel threads have good resistance to acid, alkali, high temperature and rubbing. Close structure, high intensity, good wear-resistance and high durability.
4) Production scope:
a) Length: 1m - 500m
b) Width: 914mm - 1,600mm
c) Some products' width can reach 4,000mm
d) Can be cut into coils and pieces according to customers' special requests
The following is the specification listh of your products:
| Mesh | Wire Dia(mm) | Opening(mm) | Material(AISI) |
| 2mesh*2mesh | 1.8 | 10.9 | 304 or 316 |
| 3mesh*3mesh | 1.5 | 6.96 | 304 or 316 |
| 4mesh*4mesh | 1 | 5.35 | 304 or 316 |
| 7mesh*7mesh | 1 | 2.63 | 304 or 316 |
| 10mesh*10mesh | 0.6 | 1.94 | 304 or 316 |
| 12mesh*12mesh | 0.5 | 1.62 | 304 or 316 |
| 16mesh*16mesh | 0.4 | 1.19 | 304 or 316 |
| 16mesh*16mesh | 0.35 | 1.24 | 304 or 316 |
| 18mesh*18mesh | 0.35 | 1.06 | 304 or 316 |
| 20mesh*20mesh | 0.4 | 0.87 | 304 or 316 |
| 24mesh*24mesh | 0.26 | 0.8 | 304 or 316 |
| 30mesh*30mesh | 0.3 | 0.55 | 304 or 316 |
| 35mesh*35mesh | 0.17 | 0.56 | 304 or 316 |
| 40mesh*40mesh | 0.23 | 0.4 | 304 or 316 |
| 50mesh*50mesh | 0.2 | 0.31 | 304 or 316 |
| 60mesh*60mesh | 0.15 | 0.27 | 304 or 316 |
| 70mesh*70mesh | 0.12 | 0.24 | 304 or 316 |
| 80mesh*80mesh | 0.13 | 0.19 | 304 or 316 |
| 90mesh*90mesh | 0.1 | 0.16 | 304 or 316 |
| 100mesh*100mesh | 0.09 | 0.15 | 304 or 316 |
| 120mesh*120mesh | 0.063 | 0.12 | 304 or 316 |
| 150mesh*150mesh | 0.053 | 0.11 | 304 or 316 |
| 180mesh*180mesh | 0.053 | 0.09 | 304 or 316 |
| 200mesh*200mesh | 0.04 | 0.07 | 304 or 316 |
| 250mesh*250mesh | 0.04 | 0.063 | 316 |
| 300mesh*300mesh | 0.04 | 0.044 | 316 |
| 325mesh*325mesh | 0.035 | 0.043 | 316L |
| 350mesh*350mesh | 0.03 | 0.042 | 316L |
| 400mesh*400mesh | 0.03 | 0.33 | 316L |
| 450mesh*450mesh | 0.028 | 0.028 | 316L |
| 500mesh*500mesh | 0.025 | 0.026 | 316L |
Please feel free to contact us if you are interested in our products.
