Home > Products > Marine Outfitting Equipment > Marine Aluminum Side Scuttle
Marine Aluminum Side Scuttle
- any port in China
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Jinbo | |
| Model Number | various | Part | Hinge |
Product Description
Marine Aluminum Side Scuttle
Standard: GB/T14413-93
It is also be called as porthole, the material can be aluminum, copper or steel, is used for sea-going ships and warships, also can be used for inland ship.
The side scuttle can be with or without deadlight, the deadlight also be called as storm cover.
The side scuttle can be manufacted by aluminum, steel & brass.
Size: 200mm,250mm,300mm,400mm,450mm,
Material code number | Material | Demonstration |
1 | Copper | 1. if the steel(2) main frame, copper(1) glass holder, steel(2) deadlight, the material code number is 212. 2. If aluminum(3) frame, aluminum(3) glass holder, without deadlight(0), the material code number is 330. |
2 | Steel | |
3 | Aluminum | |
0 | Without deadlight |
Opening Direction: Common hinged, Left Opening, Right Opening, or Fixed.
Plywood Case
Shipping Way: By Sea, By Air, By Courier
One-Stop Service: We supply all kinds of marine and offshore products, from securing the order to final delivery, we work hard to make sure everything goes as required and with high standard quality.
High quality: We are here to provide you with safe and reliable goods. Quality is always our main priority, our quality control program make sure that no defect or poor workmanship will be supplied. According to customer's requirement, our quality can meet the rules and standards of International Class Society such as LR, ABS, DNV, GL, BV, NK, KR, RINA, IRS and CCS.
Professional: With more than 7 years of experience in marine and offshore field, our marketing and technical team can assure you that we can understand your requirement well and deal with your inquiry professionally.
Fast Delivery: We cooperate with the reliable logistic partner, including land, air and sea to help us deliver the goods to your hand on time.
Reliable Partner: With 95% clients' satisfactory, we are confident to be your reliable partner.
We supply all kinds of marine and offshore products for various vessels including VLCC, FSO, FPSO, LNGC, LPGC, Container Ships, Cargo Liners, Bulk Carriers, Oil Tankers and oil platform, from securing the order to final delivery, we work hard to make sure everything goes as required and with high standard quality.
All Our Staff has been in marine equipment field for over 5years, has rich experience on the products they are in charge of, and can answer your technical question and the trading question.
1. All your inquiry can be replied within 24hours.
2. High quality and competitive price is always our top advantage.
