Hand push road marking sign machine 0086-18137122335
1.Motor: adopt dc brushless motor sealing, long service life, easy maintenance,
low maintenance cost.
2.Plunger pump body; Adopts full invasive lubrication oil, hydraulic power, reduce
the wear and tear. Service life of up to forty thousand hours.
3.Gasket; Using the elaborate casting from the United States imported raw materials.
Super durable, whether in winter or in summer can be used freely, acid and alkali resistance,
fatigue resistance, change of easy and convenient.
4.Absorb pipe network; Vertical body, pipettes do a cleaning easy, one can be independent
mobile convenient operation. Corrosion resistant stainless steel processing, the lining does
not fall off without clogging. Liquid absorption filter solved into the liquid surface is small,
the problem of easy blockage, increase into the liquid area, narrow space. The built-in filter.
5.The valve body. Into the liquid valve and the liquid valve adopts the ball body porcelain
beads super durable, more than the traditional steel ball than dozens of times. Continuous
surface, not broken.
6.Voltage regulation; Mechanical automatic regulating pressure stable, no pulse, oil cutting
type protection, long service life. Easy maintenance, maintenance.
Product Specification
| Hand push type cold spraying marking machine | ||||
| Item No. | X6 | |||
| Engine power | 4.3HP | |||
| Unloading flow | 6L/min | |||
| Maximum output pressure | 250bar | |||
| Nozzle standard configuration | 0.019’’ | |||
| High pressure pipe resistance to high pressure intensity | ≥350bar | |||
| Net weight | 72kg | |||
| pressure tube length | Ø 6*10m | |||
1.The frame; Adopt vertical design compact practical mobile convenience, removable, the
frame can be easily wrapped around 30 m high pressure hose, the overall equipment is easy
to do.
2.Configuration; Highpower electric and fuel type a variety of design, traffic flow,
double gun configuration can support double gun operation at the same time.
Need not equipped with air compressor, avoid double maintenance, reduce the save
maintenance costs, reduce unnecessary trouble, save energy.
All produts purchased in our company are guaranteed to keep in good repair for one year. If quality problems happen in guarantee period, our company will maintain for free.
a, Before sending the machine, we will test and adjust, so you can use directly when you get it. b, Operation video & instruction will be sent to clients, to help them use the machines better.
Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will solve your problems in time. If you are caught in some problems when using our products, welcome to contact us at any time.
a, Any problems occur while using, professional advice will be offered.
b, All kinds of frequently used parts are supplied all the year round.
c, 24 hours hot line +86-18137122335
