Help CenterOzone Generator Water Treatment for Tilapia
Related Products
Specifications
Ozone generator Water Treatment for Tilapia1.with ozone adjuster, digital timer
2.hospital air, water,
Ozone generator Water Treatment for Tilapia
Features of WZQ ozone generator:
1. Carbon steel sprayed with plastic of machine housing. Most suitable used for water treatment, as it won't be corroded eg: sewage water treatment, drinking water, aquaculture and industrial water treatment etc.
2. Installed with NT-PC10-60G/Hr enamel ozone generator tube
Water cooled for internal & external electrodes, effective prevent high temperature rising during ozone tube’s operating, for ensuring high ozone concentration output and protect the machine.
3. Adjustable ozone output: 20-100%, with digital timer.
Use high-frequency & intelligent power supply inverse system, ozone output can be adjusted on for different usage.
4. This ozone generator can feed both air and oxygen.
5. High ozone concentration is more than 90Mg/L if connect with outside oxygen tank.
6. Easy to maintain and assembly.
Specifications of NT-WZQ ozone generator:
Item |
Unit |
NT-WZQ 10g |
NT-WZQ 20g |
NT-WZQ 30g |
NT-WZQ 50g |
NT-WZQ 60g |
Oxygen flow rate |
L/Min |
1-4 |
3-10 |
3-6 |
6-15 |
8-18 |
Ozone concentration |
Mg/L |
100-66 |
104-51 |
120-94 |
115-65 |
90-58 |
Ozone output |
g/hr |
6-15.80 |
18.72-30.60 |
21.6-33.84 |
41.40-58.50 |
43.2-62.64 |
Power |
KW |
0.40 |
0.40 |
0.60 |
0.60 |
1.30 |
Frequency |
KHZ |
6 |
||||
High voltage output |
V |
PP3600V |
||||
Power amplification |
A/V |
IGBT 50A/600V |
||||
Way of cooling |
Water cooled for internal & external electrodes |
|||||
Cooling water flow rate |
L/Min |
4 |
4 |
5 |
6 |
10 |
Cooling water temperature |
°C |
30 |
||||
Adjustable(Variable control) |
% |
20-100 |
||||
Power supply |
V/HZ |
220v/110v 50/60HZ |
||||
Dimension |
mm |
460×385×840 |
||||
|
|
|
|
|
|
|
