interlocking plastic driveway soil stabilizer geocell paver for road
- 5000 Square Meter / Square Meters per Month
- Qingdao/Shanghai Port
- T/T Credit Card
-
HDPE Geocell gravel stabilizers Plastic honeycomb Geocells for Retaining Wall reinforcement slope protection driveway geocell
-
Wave Type PP/HDPE Plastic Grass Grid Grass Paver for Driveway and Parking Lot
-
50mm 75mm 100mm height HDPE geocell for driveway
-
3D Geomat
-
Flat Type PP/HDPE Plastic Grass Grid Paver for Driveway and Parking Lot
-
High Strength Road Reinforced Polyester Needle Punched Geotextile
Product Details
| Place of Origin: | Shandong, China | Brand Name: | BPM | Model Number: | BPMTG102 |
| Material: | HDPE |
Product Description
interlocking plastic driveway soil stabilizer geocell paver for road
Components and How to Use
BPM HDPE geocell is three dimensional, honeycomb like structures manufactured from high density polyethylene and jointly welded by ultrasonic technics .
It is flexible to fold during the transport and installation on construction site.
The geocell nets will be filled with soils,granular, cements or other on-site infill materials when stretched into web structures, which has powerful and rigid confinement in the lateral and vertical sides.
Note: When you are ready to inquire geocell,pls specify your requirements as followings:
1.Geoell Height(Our height range from 50mm to 200mm).
2.Welding Distance
(330mm,356mm,400mm,420mm,440mm,445mm,500mm,600mm,660mm,711mm are all available).
3.HDPE Sheet Thickness(1.1mm,1.2mm,1.5mm,1.75mm).
4.Seam Peel Strength(from 1000N/10cm to 1420N/10cm)
5.Expanded Area Size.
Enlarged Geocell Image
Product Type | Height(mm) | Welding Distance(mm) | Thickness (mm) | Tensile Strength of Welding Points(N/cm) | Tensile Strength of Connection of Cells(N/cm) | Tensile Strength at Yield of Each Sheet(Mpa) |
Smooth and Not Perforated | 50≤H≤250 | 330≤A≤1000 | 1.0~1.4 | ≥100 | ≥120 | ≥20 |
Smooth and Perforated | 50≤H≤250 | 330≤A≤1000 | 1.0~1.4 | ≥100 | ≥120 | ≥20 |
Textured and Not Perforated | 50≤H≤250 | 330≤A≤1000 | 1.5~1.7 | ≥100 | ≥120 | ≥20 |
Textured and Perforated | 50≤H≤250 | 330≤A≤1000 | 1.5~1.7 | ≥100 | ≥120 | ≥20 |
Remarks: 1. This is a basic technical specification. 2. All of the technical indexes can be reached according to the customers' demand, and the other special standards will be carried out by agreement or contact.
| ||||||
Application
Slope protection
Storage and Shipping
