Hot hydraulic automatic qt4-15 sand/cement block making machines price
It can produce all kinds of hollow blocks and solid bricks and color paving bricks,only by changing different moulds.
1.Certificates:CE/SGS/ISO9001:2000.
2.Hydraulic and Semi- automatic.
3.Strong hight-strength steel structure .
4.Block mould adopt heat treatment technology .
5.Japanese MITSUBISHI PLC/German SIEMENS or International ABB Brand motors.
6.Use worm wheel and screw mandrel to adjust the material feeder platform.
1).Main Parameters of qt4-15 sand/cement block making machines price.
| Main parameter | QT4-15 |
Control style |
Electrical control system |
| Molding cycle | 15-25s |
| Production capacity | 6000-7000 blocks/shift(8h),30000-40000 bricks/shift(8h) |
| Vibration frequency | 2800-4500r/min |
| Vibration force | 45KN |
| Host machine power |
26.45KW |
| Overall power | 48.5KW |
Voltage |
220/240/380/440V |
| Host machine size | 3550*2150*2750mm |
| Molding form | Vibration and Pressure |
| Main vibration form | Hydraulic Pressure |
Weight of host machine |
5.5T |
Size of pallet |
960*550*30mm |
|
1.Theoretical workshop area : 200m2 , need about 5-6workers. 2.The office , curing area and stacking area to arrange according your fact status. | |
2).Productivity of qt4-15 sand/cement block making machines price.
| Size(mm) | Qty/mould | Cycle molding | PCS/Hour | PCS/8hours(shift) |
| 400*250*200 | 3 |
15-25s | 720 | 5760 |
| 400*200*200 |
4 | 15-25s | 960 |
7680 |
| 400*150*200 |
6 | 15-25s | 1440 |
11520 |
| 400*100*200 | 8 |
15-25s | 1920 |
15360 |
| 240*115*52 | 26 |
15-25s | 6240 |
49920 |
| Can make all kinds of hollow and solid block(include curb stone block). | ||||
3).Complete equipemnt of qt4-15 sand/cement block making machines price.
Device |
Specification |
Power (KW) |
Unit |
Quantity |
Block machine |
QT4-15 |
26.45 |
Set |
1 |
Mixer |
JS500 |
20.5 |
Set |
1 |
Hydraulic station |
Set |
1 |
||
PLC control box |
Set |
1 |
||
Belt conveyer |
L=6M |
1.1 |
Set |
1 |
Mould |
Free |
|
Set |
2 |
Block trolley |
|
|
Set |
2 |
Spare parts and tools |
|
|
Set |
1 |
1).Raw material.
8-10% cement, 30-40% sand, 50-60% crushed stone ( you can add some other material by local situation).
2).JS500 concrete mixer.
3).Conveyor belt.
4).Hydraulic station.
1.Hydraulic station use import Electro-hydraulic,double proportional control valve.
2.The pressures and speeds can be adjusted,according to machine requirements.
3. Power saving: 30%.
5).PLC control box.
1.Adopt the latest technology,very easy to operate.
2.Can warning the faults and displaying the faults place,assure stable and high-efficiency working status.
6).Blocks/Bricks for reference.
QT4-15C Block Machine Advantage:
1.Control System:
Electric control system consists of imported color touch screen and programmed PLC with data input and output device.
2. Hydraulic System:
The system consists of imported components and seals with high dynamic performance proportional valves.
3.Frequency conversion motor drive the vibrating case,easy to obtain ideal vibration force,vibration frequency and amplitude,can produce high quality block.
4.Adopts more advanced material-feeding technology.
5.Low energy consuming.Compared with common Block Making Machine.
Inquiry service
Accept user’s enquiries by all kinds of ways and establish user’s product cognition.Provide all kinds of product data and let customer understand characteristics of product.
Pre-sale service
Accept inquiry of customers ,confirmation of investment advice of choice of product ,assist the customers to design the workshop.
In-sale service
Sale of product,help customers build the base ,technical training of customers’ workers ,practice of operation ,help to install ,train the operators in the workshop.
After-sale service
24 hours service of technology inquiry, instant components supply, regularly technical service guidance of maintain,long distance malfunction control.
Unique service
System up-grade,special design according to the customers’ requirement, mould renew ,supply new technology and products information.
Any question about concret brick making machine ,contact with us please,sincere service for you!
