Specifications
Wood Chipper:1.wood chipper capacity:8-15t/h;
2. finished wood chips:10-30mm;
3.Use:chipping wood;
4.CE,ISO
drum chipper/wood chipper /Wood crushing machine for sale engineers available to service machinery overseas (0086-18888342566)
Main material of Drum wood chipper:
Raw material for drum type wood chipper cutting is mainly small trail wood, lumbering remains (such as branches, twigs, tress etc) and woodworking remains (such as slab, plank, log core, waste veneer etc). It also can be used to chip non-lignin raw material (such as flax pole, bulrush, bamboo etc).
Introduction of Wood Chipper Machine:
TC series Drum Wood Chipper is one kind of special equipment for producing wood chips, widely used in the raw material preparing process in the factories of flakeboard, fiberboard, papermaking and wood chips making plant. Small drum type wood chipper is the best equipment for factory’s laboratory preparing material.
Features of wood chipper machinery:
1. Flexible adaptability. The design of this machine avoids making the foundation. And it is suitable for many different conditions, it does not influenced by weather and other external conditions.
2. Save time. This machine can put into produce directly which will save much time.
3. Save money. This machine has a large capacity and works reliable, only one or two person can control the machine.
Technical data of wood chipper machine:
MODEL |
TCGX215 |
TCGX216 |
TCGX218 |
TCGX2113 |
FEEDER SIZE(mm) |
160*400 |
230*500 |
300*680 |
450*700 |
QTY OF FLY KNIVES(PCS) |
2 |
2 |
2 |
2 |
SPEED OF KNIVES RUNNIN(R/M) |
592 |
590 |
650 |
500 |
MAX DIAMETER FEEDER (mm) |
160 |
230 |
300 |
450 |
WOOD CHIPS SIZE ABOUT(mm) |
30 |
30 |
30 |
38 |
CAPACITY (T/H) |
3-4 |
7-8 |
12-15 |
15-30 |
MAIN POWER (KW) |
45 |
55 |
110 |
160 |
FEEDER POWER (KW) |
2.2-3 |
3-4 |
4-5 |
7.5*2 |
OIL PUMP POWER (KW) |
1.5*1 |
1.5*1 |
1.5*1 |
3*1 |
WEIGHT (KG) |
2990 |
4070 |
7000 |
11840 |
MACHINE OUTER SIZE (MM) |
1470*1550*970 |
1800*1900*1210 |
2200*2150*1500 |
3670*2517*2050 |
BACK CONVEYOR POWER (KW) |
3 |
3 |
3 |
4 |
Working Principle of Crusher Machine:
This machine is made up of feed inlet, upper cover, rotor, hammers, pin roll, outlet, motor, base, fan blower and cyclone etc.
Materials fall into the crushing room through feed inlet. Ther are crushed under the action of high
speed rotating hammer blowing and screener friction, go through the screener hole and discharge
from the outlet unser the action of centrifugal force and flow.
Sandy Bai (Sales Rep)
Jinan Taichang Transmission Machinery Co.,Ltd
ADD: Xusheng Industrial Park, Zhangqiu, Jinan, Shandong Province, China
Mobile: +86-18888342566
MSN: jntaichang001 at
Skype: sandytc001
Email:sales006 AT
Web:
IN ORDER TO provide you the suitable product,please tell me the answers of the following question:
1.what's raw materials?
2.the moisture and size of raw materials?
3.how much production capacity you need? ( h OR d)
4.The shape and size of the final product you prefer?
5.are you product fuel or feed use it?
1.Jinan Taichang Transmission Machinery Co.,Ltd located in Shandong province,China. Our factory is a professional manufacturer of biomass pellet machine for agriculture, forest, pasturage, fishery for many years.
2.Our company has passed ISO9001-2008 quality certification , CE certification.
3. We have a perfect after-sales service system and provide customers with prompt and through service. nmmmm
