2016 High efficiency factory price drum chipperd
Raw material for drum type wood chipper cutting is mainly small trail wood, lumbering remains (such as branches, twigs, tress etc) and woodworking remains (such as slab, plank, log core, waste veneer etc). It also can be used to chip non-lignin raw material (such as flax pole, bulrush, bamboo etc).
Introduction of drum chipper:
TC series Drum Wood Chipper is one kind of special equipment for producing wood chips, widely used in the raw material preparing process in the factories of flakeboard, fiberboard, papermaking and wood chips making plant. Small drum type wood chipper is the best equipment for factory’s laboratory preparing material.
Structures of drum chipper:
drum chipper is composed of machine body ,knife chipping part ,chips re-crushing part and sieving part, ect. It combines both chipping and crushing equipment in one machine,can make sawdust in one passage, no need to use wood chipper for preprocessing of wood logs.
sawdust crusher is using slice and blow to work as double break, it will crush the branches, roots, BanPi scraps etc. which are greater than 80mm. Through this machine machining for granular, moderating to mechanisms of charcoal machine production created a condition.
Sawdust crusher for our new product, has shattered range, produced granules.
Technical data of wood chipper machine:
MODEL |
TCGX215 |
TCGX216 |
TCGX218 |
TCGX2113 |
FEEDER SIZE(mm) |
160*400 |
230*500 |
300*680 |
450*700 |
QTY OF FLY KNIVES(PCS) |
2 |
2 |
2 |
2 |
SPEED OF KNIVES RUNNIN(R/M) |
592 |
590 |
650 |
500 |
MAX DIAMETER FEEDER (mm) |
160 |
230 |
300 |
450 |
WOOD CHIPS SIZE ABOUT(mm) |
30 |
30 |
30 |
38 |
CAPACITY (T/H) |
3-4 |
7-8 |
12-15 |
15-30 |
MAIN POWER (KW) |
45 |
55 |
110 |
160 |
FEEDER POWER (KW) |
2.2-3 |
3-4 |
4-5 |
7.5*2 |
OIL PUMP POWER (KW) |
1.5*1 |
1.5*1 |
1.5*1 |
3*1 |
WEIGHT (KG) |
2990 |
4070 |
7000 |
11840 |
MACHINE OUTER SIZE (MM) |
1470*1550*970 |
1800*1900*1210 |
2200*2150*1500 |
3670*2517*2050 |
BACK CONVEYOR POWER (KW) |
3 |
3 |
3 |
4 |
Working Principle of drum chipper:
This machine is made up of feed inlet, upper cover, rotor, hammers, pin roll, outlet, motor, base, fan blower and cyclone etc.
Materials fall into the crushing room through feed inlet. Ther are crushed under the action of high speed rotating hammer blowing and screener friction, go through the screener hole and discharge from the outlet unser the action of centrifugal force and flow.ales Rep)
Jack(Sales Manager)
Jinan Taichang Transmission Machinery Co.,Ltd
ADD: Xusheng Industrial Park, Zhangqiu, Jinan, Shandong Province, China
Mobile: +86-18888342366
Skype: jack56996
Email:sales005 AT
Web:
IN ORDER TO provide you the suitable product,please tell me the answers of the following question:
1.what's raw materials?
2.the moisture and size of raw materials?
3.how much production capacity you need? ( h OR d)
4.The shape and size of the final product you prefer?
5.are you product fuel or feed use it?
1.Jinan Taichang Transmission Machinery Co.,Ltd located in Shandong province,China. Our factory is a professional manufacturer of biomass pellet machine for agriculture, forest, pasturage, fishery for many years.
2.Our company has passed ISO9001-2008 quality certification , CE certification.
3. We have a perfect after-sales service system and provide customers with prompt and through service. nmmmm
