animal feed ring die pellet mill/animal feed machine plant (008618888342366)
Brief Introduction of animal feed ring die pellet mill:
This high quality animal feed ring die pellet mill has small volume, low noise, and simple structure. It has wide scope of application, for example, nearly all the rural breeding farmers and farms (such as rabbit, pig, cattle, etc) chose this machine to make feed pellets.
The particle made by this animal feed ring die pellet mill has high hardness, smooth surface, fully internal curing degree. Therefore, the feed pellet produced by this machine can improve the animal digestion, avoid the picky of the livestock, and finally the pellets are conductive to the animal nutritional balance. Users can get the biggest benefit from this machine.
Features of animal feed pellet mill:
Ring die pellet
mill has large diameter ring dies , which can make materials fully cured and pellets smoother. the friction can be fallen to the bottom.key parts are made by our CNC system ,which is high precision and quality, so we can ensure pressing efficiency.
Process and principle of animal feed pellet mill:
Ring die pellet mill has forced material-entrance equipment and overload protection device ,which makes machine more safe to work. Also has changeable speed feeder and conditioner , the feeder can adjust feeding materials speed .Conditioner will connect with steam to soften materials.
When ring die pellet mill works, rollers and ring die touch with each other in a vertical type--rollers rotary and ring die keep stable , in this way produce large capacity production.
Technical Parameters of animal feed pellet mill:
Model |
Power(kw) |
Output (t/h) |
Pellet (mm) |
External Dimension (mm) |
TCZL250 |
22+1.5+1.5 |
0.6-1.5 |
2-8 |
1320×330×850 |
TCZL300 |
45+2.2+1.5 |
1.5-2.5 |
2-8 |
2100×1550×1060 |
TCZL350 |
55+2.2+1.5 |
3-5 |
2-8 |
2220×1160×1450 |
TCZL450HA |
90+3+3+1.5 |
4-8 |
2-8 |
2400×1200×1600 |
TCZL450HB |
110+3+3+1.5 |
6-12 |
2-8 |
2600×1400×1800 |
TCZL610 |
150+3+3+1.5 |
12-15 |
2-8 |
3200×2350×2200 |
We have a perfect after-sales service system and provide customers with prompt and through service.
Jinan Taichang Transmission Machinery Co.,Ltd located in Shandong province,China. Our factory is a professional manufacturer of biomass pellet machine for agriculture, forest, pasturage,fishery for many years.
Our company has passed ISO9001-2008 quality certification and CE certification.
In order to offer you the reasonable machines,we need more details as followings:
1.What’s your raw materials?
2.What’s the size of raw materials?
3.What’s moisture content of materials?
4.What’s size of pellet you want?
