Specifications
board frame type sludge dewatering equipment, medical waste treatment equipment1 durable
2 efficiency
board frame type sludge press equipment, medical waste treatment equipment
Plate-frame type sludge
The frame filter press is one kind of intermittent liquid-solid splitter, is by filters the board, the filtering frame arrangement constitution straining chamber, in loses under the material pump's pressure function, will expect the fluid to feed in various straining chambers, through filter medium, solid and liquid separation. Widely applies in chemical, the dye, the petroleum, ceramic, the drugs manufacture, the sugar manufacturing, food, the starch, the malt sugar, the paint, the metallurgy and various professions sewage treatment and so on. It has the separation effect, the applicable scope to be broad well, merits and so on simplicity of operator, investment province, specially to stick the thin material the separation, has the incomparable superiority.
| specification | filtration area | frame inside dimension | fliters cake thickness | filters the board quantity | filtering frame quantity | external dimensions | filteration pressure | electrical machinery power |
| 15/630 | 15 | 630×630 | 30 | 18 | 19 | 2820×1110×1190 | 0.6 | 2.2 |
| 30/630 | 30 | 630×631 | 30 | 37 | 38 | 3960×1110×1190 | 0.6 | 2.2 |
| 50/800 | 50 | 800×800 | 30 | 38 | 39 | 4615×1260×1350 | 0.6 | 3 |
| 80/800 | 80 | 800×801 | 30 | 62 | 63 | 6295×1260×1350 | 0.6 | 3 |
| specification | filtration area | frame inside dimension | fliters cake thickness | straining chanmber volume | filters the board quantity | external dimensions | filteration pressure | electrical machinery power |
| 15/630 | 15 | 630×630 | 30 | 226 | 18 | 2700×1060×1150 | 0.6 | 2.2 |
| 30/630 | 30 | 630×631 | 30 | 748 | 37 | 3990×1270×1300 | 0.6 | 3 |
| 50/800 | 50 | 800×800 | 30 | 1219 | 38 | 4760×1400×1400 | 0.6 | 3 |
| 80/800 | 80 | 800×801 | 30 | 1861 | 62 | 6140×1400×1400 | 0.6 | 3 |
the packageing of board frame type sludge filter press
Plate-frame type sludge
The frame filter press is one kind of intermittent liquid-solid splitter, is by filters the board, the filtering frame arrangement constitution straining chamber, in loses under the material pump's pressure function, will expect the fluid to feed in various straining chambers, through filter medium, solid and liquid separation. Widely applies in chemical, the dye, the petroleum, ceramic, the drugs manufacture, the sugar manufacturing, food, the starch, the malt sugar, the paint, the metallurgy and various professions sewage treatment and so on. It has the separation effect, the applicable scope to be broad well, merits and so on simplicity of operator, investment province, specially to stick the thin material the separation, has the incomparable superiority.
Zhucheng Yonglida Machinery Limited Company is located in Zhucheng city, Shandong province, China and founded in 1993 covering an area of 30,000 square meters. It is the high technology factory combined with design, development, production and technical service and leads the papermaking equipment and environmental protection equipment industry in China.
Main products: Toilet paper making machine, cardboard paper making machine, corrugated paper making machine, craft papermaking machine, environmental protection equipment, daily and city waste water and daily garbage treatment equipment, industry waste water and garbage treatment equipment, paper making, printing, starch, medical and mine industry waste water treatment equipment, etc.
Yonglida has operated several papermaking system and environment protection project domestic and foreign, including Russia, Egypt middle east, etc. We can also make the proper project plan as customer’s requirement.
Welcome to visit our factory, hope we could have a long cooperation relationship and business win win.
