Specifications
2460mm Paper Machine1 durable
2 professional technology service
3 high efficiency
4 simple to maintain
2460mm Paper Machine
usage:
we can offer many kinds of facial tissue paper machines in different type.
If you have interests in our products please tell us the following questions :
1 what kind of paper do you want to produce
2 what is your raw material
3 your expect daily output
Technical Specification:
1. Folding roll width: Max. 2100mm
2. Original paper: 18-30gsm (1 layer) virgin pulp towel paper
3. Finished open size:210±2mm X (140-230) mm
4. Folded size: 105±2mm X (140-230)mm
5. Folding type: V type
6. Folding speed: 500~1000sheets/min/line
7. Transverse paper cutting knives type: Upper knives: each 1 fixed integral high-speed steel knife at front and back. Under knives: each 3 turning integral high-speed steel knife at front and back.
8. Lengthways cutting knife:
9. Edge embossing device (front and back)
10. 4pcs of chrome-plated steel embossing rolls, pneumatic pressure device.
11. Original paper roll width: Max.2050mm
12. Original paper rolls diameter: Max. 1200mm
13. Paper core diameter:76.2mm
14. 2 paper stands with pneumatic paper lifting device.
15. Paper tension adjusting device: manually.
16. Left and right adjusting: manually
17. Driving type: synchronous gearing belt or flat belt
18. Control type: Inverter speed control.
19. Counting type: photo-electric sensing device, counting device setting, right and left misalignment counting device
20. Emergency breaking button and inching button
21. Roots vacuum pump: Longtech
22. Pneumatic system pressure: >4kg/cm2 (prepared by buyer)
23 Embossing: Steel to steel.
more details:
| Machine Classify | Foundation |
| Machine Model | CB228 9T |
| Jumbo Roll Dimension | 1,800mm(W) |
| Jumbo Roll Diameter | 1,000mm(Ø) |
| Jumbo Roll Material Qualify | Paper Basic Weight: 12~15 gsm/1 ply |
| Paper Material:100% pure paper | |
| Jumbo Roll Paper Core: 3 inches | |
| Jumbo Roll Unit:2 units | |
| Interfold Style | V Fold |
| Unfold Dimension | 200mm(L)x 200mm(W) |
| Interfold Dimension | 100mm(L)x 200mm(W) |
| Slitting Knives | 2 units |
| Machine Design Speed | 90~100M/min |
| Design Product Capacity | 8,000 sheets/min |
| Remark | Customer could flexible to change as your specific dimension |
sea worthy package
1.Pre-sales Service
1.Offering comprehensive technical and business consultation services;
2.Proposing the most suitable scheme and equipment for our clients;
3.Designing and fabricating targeted products according to the special requirements of clients;
4.Training periodically high qualified service technician.
2.After-sales Service
1.Highly inspecting equipments in every working procedure, quality comes first;
2.Fast & Safe Delivery;
3.Assisting our clients for foundation construction of equipments;
4.Dispatching engineers to install and debug equipments;
5.Training the first-line operators on site;
6.Regularly visit clients to solve production problems;
7.Providing life-long maintenance service;
8.Providing technical exchanging;
ABOUT OUR COMPANY:(Facial tissue paper machine)
Zhucheng Yonglida Machinery Limited Company is located in Zhucheng city, Shandong province, China and founded in 1993 covering an area of 30,000 square meters. It is the high technology factory combined with design, development, production and technical service and leads the papermaking equipment and environmental protection equipment industry in China.
Main products: Toilet paper making machine, cardboard paper making machine, corrugated paper making machine, craft papermaking machine, environmental protection equipment, daily and city waste water and daily garbage treatment equipment, industry waste water and garbage treatment equipment, paper making, printing, starch, medical and mine industry waste water treatment equipment, etc.
Yonglida has operated several papermaking system and environment protection project domestic and foreign, including Russia, Egypt middle east, etc. We can also make the proper project plan as customer’s requirement.
Welcome to visit our factory, hope we could have a long cooperation relationship and business win win.
if you have any questions please let me know.
