Steam heat hot air circulation fish drying machine price
- 10 Set / Sets per Month
- Qingdao
- T/T
Product Details
Condition: | New | Brand Name: | AZEUS | Model Number: | CT-C-IV |
Type: | Dryer | Voltage: | 220V/380V | Power(W): | 60kw |
Weight: | 2200kg | Dimension(L*W*H): | 4460*2200*2290mm | Certification: | CE ISO |
Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Steam heat hot air circulation fish drying machine price
Brief introduction
Working principle:Hot air circulation inside the oven, and automatic temperature controlling system
Body material:
1. Carbon steel outside and stainless steel inside;
2. Stainless steel both outside and inside;
3. All the drying trolleys and baking trays are made of stainless steel.
Type: Batch type
1. 60kg/batch
2. 120kg/batch
3. 240kg/batch
4. 360kg/batch
5. 480kg/batch.
Application of fish drying machine
This drying machine can be used in many fields, such as food processing industry, fruit and vegetable processing industry, agricultural and sideline industry, seafood processing industry, medicinal industry,chemical industry, etc.
- Dried fruits: apple, lemon, berry, banana, kiwi, figs, pear, peach, pineapple, mango, jujube, plums, etc.
- Dried vegetables: mushroom, pepper, carrot, cabbage, red chili, onion, tomato, potato, sweet potato, garlic, ginger, etc.
- Dried nuts: cashew nuts, walnuts, peanuts, etc.
- Dried beans: cocoa beans, peas, red beans, green beans, black beans, etc.
Specification and picture of each model
AZEUS-CT-C-I fish drying machine
Capacity: 120 kg /batch Fan power: 0.45kw Total power: 15kw Mobile trolleys: 2 units |
Drying trays: 48 pcs Size: 2300*1200*2300mm Weight: 600kg |
AZEUS-CT-C-II fish drying machine
Capacity: 240 kg /batch Fan power: 0.9kw Total Power: 30kw Mobile trolleys: 4 units |
Drying trays: 96 pcs Size: 2300*2200*2300mm Weight: 1800kg |
AZEUS-CT-C-III fish drying machine
Capacity: 360 kg /batch Fan power: 1.35kw Total power: 45kw Mobile trolleys: 6 units |
Drying trays: 144 pcs Size: 2300*3220*2000mm Weight: 2000kg |
AZEUS-CT-C-IV fish drying machine
Capacity: 480 kg /batch Fan power: 1.8kw Total power: 60kw Mobile trolleys: 8 units |
Drying trays: 192 pcs Size: 4460*2200*2290mm Weight: 2200kg |
Parts
Temperature controller & Axial flow fan & heating pipes
Features
- Heat efficiency: The entire circulatory system is fully enclosed, to improve the heat efficiency from traditional 3-7% to present 35-45%, highest can reach 50%.
- Operation: Automatic temperature control system, easy to operate. Trolleys with wheels on the bottom.
- Heating ways: The heat source can be electricity, steam, gas, coal burning, or dual-use. And please note, usually the machine is equipped with electricity heating way, if choose other heating ways, the machine should work with a furnace or steam boiler.
- Trolleys & trays: The drying trolleys and drying trays are all made of stainless, and are included in the quotation offered.
- Voltage to confirm: Voltage can be customized. So please kindly tell us _phase, _V, _Hz when send inquiry.
Dehydrated samples
1. The drying time of this drying machine will vary by different materials, moisture content, sugar content, local climate, etc.
2. Fruits can be dried whole, or as slices, such as mango, papaya, and kiwi, etc. Alternatively they can chopped after drying, made into pastes, or concentrated juices.
3. Dried fruit is widely used by the confectionery, baking and sweets industries.
4. Food manufacturing plants use dried fruit in various sauces, soups, marinades, garnishes, puddings, etc.
Package and delivery
If any needs or questions about our fish drying machine, please send me inquiry here, or contact me via the following information:
Contact person: Grace
Email: joywan(at)
WhatsApp: 0086 15617773482
Skype: gracexie55
