model 1092 toilet paper make machine ( productivity 2tons/day)
No. |
Commodity name |
Specifications (kw) |
Amount |
1 |
2m3Vertical high-concentration deinking pulper |
17kw , 5-10tons/day,pulp concentration 5% |
1 set |
2 |
0.9m2 Square vibration sieve |
1.1kw, diameter of sieve hole:0.35mm, inlet pulp concentration: 1-1.5%, capacity 2-2.5ton/day |
1set |
3 |
Dual Disc refiner |
7.5kw, specification 250mm, Inlet concentrate: 2-5%,inlet pressure 0.1-0.3Mpa Capacity 3-8ton/day |
1set |
4 |
Vacuum pump |
4kw, type 33 |
1set |
5 |
Potcher |
5kw, capacity 25m3, |
2set |
6 |
Pulping pump |
3 kw, inlet concentrate : 2-10% Lift : 16m, flow:40m3/h |
6set |
7 |
Centrifugal pulp-screen |
4kw, type 0.3 |
1set |
8 |
Vertical Mixer |
1.5kw, volume of pump tank: 30m3 Pulp concentration:2-5% Impeller diameter : 2000mm,speed 12r/min
|
3et |
9 |
Model 100 White water pump |
5kw, Inlet concentration: 3-10%,lift 18m Flow: 120m3/h
|
1set |
10 |
Model 1092 paper machine |
3kw |
1set |
11 |
1092 rewinder perforated machine |
1.1 kw |
1set
|
12 |
Paper scroll cutting machine |
1.1 kw |
1set |
13 |
boiler |
|
1set |
1.Area covered : 120--150m2
2.Water capacity : 3-5m³/h
water require : PH<7 suspended particles <0.15/L(no pollution)
3.The total installed capacity : 85KW(actual normal work 65 kw)
working voltage : 380V.220V current frequency : 50-60Hz
5.Operating personnel : 3-5people/class
6.Energy demand : working pressure 0.3Mpa--0.6Mpa.
To be equipped with 1 tons of diesel cosume boiler 1 set
7,use waste paper 2.5—4T/day
8 need use a 40GP container
TECHNICAL DATE
1 Output paper:premiere brand toilet paper
2 Output rate: 13--30g/m2
3 The paper width:1092mm
4 The cylinder width: 1350mm
5 Design speed: 50-100m/min
6 Working speed: 50-80m/min
7 The capacity: 1.5--2T/D
8 The gauge: 1800mm
After sale service:
1,The company strictly in accordance with the signed device configuration and technical requirements ,According to the national industry standard for design and manufacturing, and guaranteed to the user's device is compliant qualified products.
2, After the commencement of the contract, within ten days of the equipment design and manufacturing company,End-user installation process coordination, convergence, and inspection;Business contacts on both sides of the letter have to be back within 8 hours.
3, In accordance with the mutually agreed time and the cycle for equipment installation, and commissioning.
4, Equipment quality and shelf life of one year, the vulnerability is not within the guarantee period.Package of quality roller shelf life of six months.Refers to all goods shipped to the user The date of acceptance for the quality of shelf life.
5, The quality warranty period, the company free of charge to provide the necessary technical services, Occurred as a result of equipment design, manufacturing quality problems lead to equipment, the company will Responsible for replacement and maintenance.
6, After shelf life, the company to provide customers with technical services for life, and long-term To price and quick delivery of spare parts, spare parts.
7, The company responsible for all production technologies and installation, conferred to production workers, Ensure that the church workers to operate.
