Best Price paper napkin making machine Engineer install Abroad Welcome to See Running machine
The basic technical parameter of - paper napkin making machine
1. 1575 paper napkin making machine
2. Output paper: Toilet paper,napkin paper
3. Gram weight(g/m2)12—48g/m2
4. Net paper width (mm): 1575mm
5. Design work speed (m/min):100----150m/min
6. Work speed (m/min): 80--120m/min
7. Daily capacity (t/d): 3-4t/d ( based on different size dryer )
8. Drive way: AC variable frequency, section drive
9.Model design: Box structure, operation by left or right hand
10. Sizing way: Inversion Pulping
11. Matched felt: Normal Chemical fiber woven felt
12. Forming wire type: Stainless Steel plate
13 structural layout: Monolayer
14. Power (v, HZ): standards 380v/50HZ/3 phase ( if need we change voltage,please tell us )
15. Pneumatic medium: Compressed air, 0.6 MPa, level 3 industrial compressed air standards
16.Steam: 0.3MPa-0.6Mpa
17. Water quality standard: PH-7, total alkalinity（take CaCO3 as example, mg/L）≤350
18. Factory area: 300-400m2
19.Worker number: 5-8 worker
20. Raw material: Rice straw, wheat straw, wood, waste paper, virgin pulp ( different raw materials need use
different paper pulp machines, so better tell us your raw materials in advance)
Contact
For more details of Best Price paper napkin making machine Engineer install Abroad Welcome to See Running machine
Please Contact Whatsapp +8618537138115
The paper napkin making machine with models we have :
600/787/1092/1200/1575/1600/1760/1880/2400/2880/3200/etc for choose etc
Welcome contact us by tell us more detailes include your raw materials,your final products, your daily capacity to help us suggest and make best quote for you
Machine Parts-paper napkin making machine
Name: Cylinder
Materials:
Stainless steel structure for the film, cast iron spokes
Bearing :113622(3618)Main Parts-paper napkin making machine
Name : dryer
Materials:
Cylinder block material: HT200
Cylinder head: HT250
Surface hardness: HB220
Surface roughness: ≤0.9 mu
The highest work pressure: 0.35MPa
Hydrostatic pressure: 0.8MPa
Bearing: 3113168
Machine Parts-paper napkin making machine
Name: couch roller
Materials:
rubber hardness:shore A38±2°
Cladding thickness: 25mm
Spindle nose: 45＃steel for thermal refining
Bearing: 113620
Main Features-paper napkin making machine
Name: rack
Materials : Rack beams, pressure arm for the Q235 steel plate or cast iron box-type structure
Pre-Sales Service -paper napkin making machine
* Inquiry and consulting support.
* Come to our factory to see machine
* View local customers' running factory
After-Sales Service-paper napkin making machine
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
