2.2 mm , 2.5 mm , 2.7 mm , 3.0 mm , 3.4 mm Zinc Aluminium Alloy Wire (directly factory)
Resistance Zin Alununum Alloy Wires is used for electrical heating element.
Widely used in metallurgy, industrial stoves, household appliances, machinery and electronics manufacturing industries do heat resistance material.
Material: Zin Aluminum Alloy
Wire Diameter: 1.8mm---4.0mm
Hot sale specifications : 2.2mm , 2.5mm , 2.7mm , 3.0mm , 3.4mm
Features:
1)high electrical resistivity
2)good corrosion resistance under high temperature
3)1Cr13AI4, 0Cr21AI4, 0Cr21AI6, 0Cr25AI5
Technical Information:
| Grades | 1Cr13AL4 | 1Cr21AL4 | 0Cr21AL6 | 0Cr23AL5 | 0Cr25AL5 | 0Cr21AL6Nb | 0Cr27AL7Mo2 |
| Main chemical composition% | |||||||
| Cr | 12.0-15.0 | 17.0-21.0 | 19.0-22.0 | 20.0-23.5 | 23.0-26.0 | 21.0-23.0 | 26.5-27.8 |
| AI | 4.0-6.0 | 2.0-4.0 | 5.0-7.0 | 4.2-5.3 | 4.5-6.5 | 5.0-7.0 | 6.0-7.0 |
| Fe | balance | balance | balance | balance | balance | balance | balance |
| Re | appropriate | appropriate | appropriate | appropriate | appropriate | appropriate | appropriate |
|
Components maximum use temperature |
950 | 1100 | 1250 | 1250 | 1250 | 1350 | 1400 |
| Melting point | 1450 | 1500 | 1500 | 1500 | 1500 | 1510 | 1520 |
|
Density g/cm3 |
7.4 | 7.35 | 7.16 | 7.25 | 7.1 | 7.1 | 7.1 |
|
Resistivity μΩ·m,20 |
1.25±0.08 | 1.23±0.06 | 1.42±0.07 | 1.35±0.06 | 1.42±0.07 | 1.45±0.07 | 1.53±0.07 |
|
Tensile strength Mpa |
588-735 | 637-784 | 637-784 | 637-784 | 637-784 | 637-784 | 686-784 |
wooden boxes or as clent's damand for Aluminium Alloy Wire
Welcome to ANPING NO.2 WIRE MESH FACTORY.
Anping NO.2 Wire Mesh Factory was founded in 1984, sharing 20 years' wire mesh production history.We are a professional manufacturer of various kinds of metal mesh.We have Roberts workshop, weaving workshop, the template network workshop, deep-processing workshop and so on.
The main products of our factory:
1. WIRE: Stainless Steel wire, Black Iron Wire, Galvanized Wire and Zinc Alumimun Alloy Wire
2. WIRE MESH: Stainless Steel Wire Mesh, Crimped Mesh, Corner Mesh and Window Screening.
3. WELDED: Welded Wire Mesh, Welded Panel and Steel Grating.
4. FENCING: Chain-Link fence, Palisade Fence, Welded Panel Fence and (Razor) Barbed Wire Mesh.
5. LINTEL: U-Lintel and W-lintel.
1 . Any Inquiries will be replied within 24 hours .
2 . We are professional metal wire mesh manufacturer and factory with more than 30 years' experience .
3 . We have technical designers who can design metal wire mesh products as per customers' requirements .
4 . Quality Guarantee :
----- All products will be strictly inspected by our inspector before packing and shipping .
----- Welcome to our factory to supervise the manufacturing processing and inspect our products whenever .
----- If the material , weight and appearance can not meet your markets requirements , we are commited to
unconditional return the products and refund , then compensate you the corresponding .
5 . Free Samples .
Thanks for your attention on us . If you are interested in any of our products , please feel free to contact with me .
