Newly Design Cocoa Bean Grinding Machine/onion Powder Making Machine

Newly Design Cocoa Bean Grinding Machine/onion Powder Making Machine thumbnail-1
Newly Design Cocoa Bean Grinding Machine/onion Powder Making Machine photo-1
US$ 1,000 - 5,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
FX
Model Number:
FX-180
Contact Supplier Request Quote Chat Now
Zhengzhou Fusion Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao shanghai tianjin Newly design Multifunctional grain crusher/sugar fine powder making machine/chemical material grinder
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name FX
Model Number FX-180
Type Grain Processing Equipment
After-sales Service Provided Engineers available to service machinery overseas

Newly design cocoa bean grinding machine/onion powder making machine

Working Principle of cocoa bean processing equipment

This  grain crusher is designed for using the high speed rotation between movable teech disc and Fixed Fluted Disc to crush the raw material into powder via the effect of impact , friction and collide from the material or teech disc. Then the shredded material flows out from the grinder chamber via discharge hole, and the fineness are controlled via adjust the different screen.



The  grain crusher structure is simple,sturdy,stable operation,crushing material quickly,evenly to good effect . The  grain crusher are all made of SUS 304 stainless steel , machine shell internal(crushed slot)all alveolar precision machining to achieve a smooth surface,easy to clean,so that food,drugs,chemical production more in line with national standards,to achieve the health requirements of the GMP.



Features of cocoa bean processing equipment



1.SUS 304 good quality stainless steel



2.high quality motor which use copper wire



3.the replacement of the screen can control the grinding granularity size .



Application of powder grinder mill :



Chemical material,traditional Chinese medicine,tree branch and block shape material , oily grain seeds(sesame,walnut,ground nut,dry red dates and etc) , varies of spice material,coarse cereals and other hard or brickle material.

Technical parameters of cocoa bean processing equipment



Model

FX-180

FX-250

FX-320

FX-350

Material

Stainless steel

Stainless steel

Stainless steel

Stainless steel

Voltage(v)

220/380

380

380

380

Power(kw)

2.2

5.5

7.5

11

Speed

4200

4200

4200

4200

Fineness (mesh)

10-2000

10-200

10-200

10-200

Capacity

(kg/h)

10-120

30-200

50-300

70-500

Overall dimensions (mm)

480X520X1040

750X600 X1260

780 X700 X1350

800 X900 X1550

Weight (kg)

75

180

260

320



Have machine in store,if interested please contact me,thanks



Pictures of  cocoa bean powder



Newly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machine



Newly design cocoa bean grinding machine/onion powder making machine

Newly design cocoa bean grinding machine/onion powder making machine

Newly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machine



Newly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machine

Newly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machine

Fianl products

Newly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machineNewly design cocoa bean grinding machine/onion powder making machine
