CE Certification Approved Spiral Freezer of High Efficiency 2015

CE Certification Approved Spiral Freezer of High Efficiency 2015 thumbnail-1
CE Certification Approved Spiral Freezer of High Efficiency 2015 photo-1
US$ 47,850 - 67,850 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Spiral Freezer
Place of Origin:
Jiangsu, China
Contact Supplier Request Quote Chat Now
SSS Hardware International Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Spiral Freezer
Place of Origin Jiangsu, China
Brand Name SSS
Model Number SSS-DL300
Voltage customized
Power(W) bases on design
Dimension(L*W*H) bases on design
Weight bases on design
Certification ISO9001
Warranty 1YEAR
After-sales Service Provided Engineers available to service machinery overseas

Single spiral freezer



1. freezing product and temperature

Freezing product: fish, meat, seafood, pastry, poultry, ice cream, etc.

Freezing capacity: 300kg/hour

Freezing method: IQF

Temperature of inlet: 15°C

Temperature of inlet: -18°C

Temperature of evaporation: -42°C

Temperature of inner: -35°C

Freezing time: 15-90 min (adjusted)





2. technical data

Model: SSS-DL300

diameter of tumbler: 2500mm

net height between layers: 200mm

belt width: 500mm

belt length: 185m

inlet length: 2300mm (equipped with cleaner and blower)

outlet length: 1000mm

freezer dimension: 7600*3700*3300mm

power: 11kw





3. main characteristics

1) Conveyor belt is made of special high strength stainless steel 304 which can meet food grade, running smoother and lasting longer;

2) All components can fully meet the hygienic requirements of HACCP;

3) This equipment is in life-long design which is structured as installation not welding, it will be much easier to maintenance;

4) Driving control is made of fine stainless steel;

5) There is unique design of symmetrical and fluent circle wind channel, which can keep cold in inlet and outlet;

6) It is equipped with evaporation in high efficiency which is 30% higher than common evaporation;

7) The bottom is made of stainless steel in 3mm thick,no leak and no risk of burst;

8) Main control components are from Schneider, and control box is made of stainless steel;

9) Reducer is from SEW, which can ensure high efficiency and long life.





4. This machine can be customized as per your requests.

 CE certification approved spiral freezer of high efficiency 2015
