Mini Fish Meal Plant Made in China

Specifications

 Mini Fish Meal Plant

1. raw material and capacity

Raw material is fresh fish, and fish consumption is 300kg/hour

2. final product

Amount: 80kg (from 300kg raw material)

Note: usually the amount is based on fish type and fish quality

Skimmed fish meal with moisture ≤12%

3. Procedure

Raw material -> cooking and pressing -> drying -> skimmed fish meal

1) heating method: electrical heating of thermal oil 200°C

2) total power: 40kw

3) processing method: cooking, pressing, drying

4. Specification of equipment

1) Screw conveyor

dimension: φ170×4000mm;

equipped with cycloidal reducer 1 set,

made of SUS304;

power: 1.5kw

2) crusher

dimension: φ400×1000mm

equipped with cycloidal reducer 1 set,

power: 4kw

3) cooker

dimension: φ377×3500mm;

equipped with converter motor 1 set;

material of outer heat preservation made of SUS430, thickness: 0.7mm;

inner and outer cylinder made of Q235B;

driving power: 1.5kw

4) screw press

dimension: φ219×1000mm;

equipped with converter motor 1 set;

outer cover made of SUS430, thickness 0.7mm;

inner and outer cylinder made of Q235B;

power: 1.5kw

5) dryer

Dimension: φ820×3500mm

equipped with reducer 1 set;

inner and outer cylinder made of Q235B;

material of outer heat preservation made of SUS430, thickness 0.7mm;

driving power: 4kw

6) electric control cabinet 1 set

7) Other supporting equipment, fittings and appliances
