Competitive price mud pump /slurry pump
1.Brief introduce
JT & JU series Competitive price mud pump /slurry pump is our latest generation product base on US technology and craftwork. It is designed for economical & trouble-free operation in handling solid-laden liquids and slurries.
2.Specifications
Model: JT-2,JT-3, JT-4, JT-6,JT-8,JT-10,JT-12
(50mm,75mm,100mm,150mm,200mm,250mm,300mm)
Max. capacity: 2~1275m3/h
Max. Head:2-43m
lids:76mm
Max. temperature:160F(71degree)
Materials of Construction: Cast iron,ss304,ss316,ss316l
Engine:Cummins,Perkinks,Deutz,Chinese Diesel engine,Electric Motor or as customer request.
Engine type: Water cooled/Air cooled
Method of Connection:Moto mounted,engine mounted,V-belt driven
Skid Mounted on the Trailer : 2 or 4 wheels trailer
Package: Standard export plywood case
3.Parameters Table
| MODEL | size | R.P.M. R/MIN | MAX FLOW (m3/H ) | Max Head (m) | Suction Lift ( m ) | Power ( HP) | MAX SOLIDS mm | NET WEIGHT kg | GROSS WEIGHT kg |
| JT-2 | 2 inch | 1150-2900 | 46 | 36 | 7.6 | 1 – 10 HP | 44.45 | 92 | 114 |
| JT-3 | 3 inch | 650-2150 | 107 | 35 | 7.6 | 1 – 20 HP | 63.5 | 183 | 205 |
| JT-4 | 4 inch | 650-1950 | 163 | 36 | 7.6 | 1 – 30 HP | 76.2 | 259.5 | 280 |
| JT-6 | 6 inch | 650-1550 | 330 | 33 | 7.6 | 2 – 40 HP | 76.2 | 364 | 391 |
| JT-8 | 8 inch | 650-1350 | 600 | 34 | 7 | 7.5 – 75 HP | 76.2 | 581 | 634 |
| JT-10 | 10 inch | 650-1450 | 775 | 40 | 6.7 | 10 – 100 HP | 76.2 | 635 | 663 |
| JT-12 | 12inch | 650-1250 | 1275 | 42 | 4.9 | 20 – 125 HP | 50 | 998 | 1066 |
| JU-3 | 3inch | 850-2150 | 85 | 62 | 7.6 | 1.5 – 25 HP | 20.63 | 214 | 225 |
| JU-4 | 4 inch | 850-2150 | 148 | 60 | 5.2 | 3 – 40 HP | 28.57 | 272 | 297 |
| JU-6 | 6 inch | 850-1950 | 308 | 58 | 4.5 | 5 – 75 HP | 31.75 | 413 | 437 |
More parameters please contact us!(Skype:defucc2,Whats App: 18957752761)
4.Performance Curve
5.Advantage
1)Originally form USA Patent design
2)Excellent&reliable performance
3)Non-clogging design
4)Excellent self priming function
5)Dry installed,easy installation and maintainance
6)The best replacement of QW pumps
7)Fully interchangeable with Gorman Rupp T& U series
6.Application
1)Air ConditioningPressure Boosting
2)Fire ProtectionCooling Towers
3)Plumbing Irrigation
4)Circulating Water Treatment & Supply
5)TransferChemical
6)Sea Water Treatment
7) Sewage pump, hose for pumping sewage, marine sewage pump
1 pc for 1 plywood case,exporting plywood case or as clients'requirement.
DEFU PUMPS
About Us
DEFU Machinery is an Enterprise involved in designing ,developing ,manufacturing and selling water pumps , Including self priming pump ,centrifugal pump ,diaphragm pump , gear pump , diesel engine pump and some others . Relying on the local industrial chain , DEFU has established its production base in Shanghai ,Hubei and Shandong province .
Website:
Working Shop
