JK-MSH-Pro-2B Digital Magnetic Stirrer With Hotplate

JK-MSH-Pro-2B Magnetic Stirrer(With hotplate)

Features:

• Magnetic stirrer suitable for unsupervised operation, with new stir technology

• Automatic judgment stirring bar displacement and capture
• Hotplate with stainless steel surface or porcelain enamel surface with excellent chemical resistance
• Every point independently control speed,easy-to-read backlit LCD display
• Fuzzy logic control microprocessor technology guarantee maximum control accuracy
• Multiple modes ensure the stirring function not change due to external factors
• With the control of safe temperature ,suitable for unsupervised operation
• 2 adjustable safety circuits ,separateness temperature sensor, protection temperature can be set
• Temperature sensor for heat transfer fluid and medium available(PT1000)
• Warning display indicating presence of any residual heat when the unit is switched off

Specifications
Voltage[VAC] :110/220 ;
Frequency[Hz] :50/60;
Power[W]: 500*2;
Stirring point position quantity :2;
Max. stirring quantity(H2O)[L] :5;
Stirring point position quantity[mm] :30;
Motor type: brushless motor ;
Motor rating input[W]: 3;
Motor rating output[W] :4;
Speed range[rpm] :100-1500;
Speed display: LCD ;
Speed display accuracy[rpm] :1 ;
Material: Ceramic surface/Stainless steel;
Heating power [W] :500X2;
Heat rate(1Lwater)[K/min]:6;
Heating Temperature Range [℃]: RT-350;
Temperature display: LCD;
Temperature display accuracy[℃] :0.1;
Control accuracy of heating temperature[℃]:1;
Safety temperature[℃] :100-350 ;
Temperature sensor of extra position: PT1000;
Control accuracy of heating temperature with temperature sensor [℃]: 0.2
Dimension[cm]:23*33*9
