Agri- Waste Hammer Mill
1. Agri- Waste Hammer Mill is mainly used to crush wood, wood waste, wood shaving, wood chips straw shell rice husk etc into powder. Fineness can be 1-20mm.
2. Agri- Waste Hammer Mill can crushe fertilize waste such as animal manura,plant waste etc, also can crush animal feed materials such as soybean, maize, grain, etc. Tell us what kind of raw materials will crushe and the last dimension after crushed, then we will help you choose best models.
3. Agri- Waste Hammer Mill is mainly used in wood factory, feed factory, cultivation factory, Fertilizer, chemical industry , power plant and so on.
Spare parts of wood hammer mill crusher machine :
4. Agri- Waste Hammer Mill usually works with cyclone, air lock, fan blower, bag dust collector, air control pannel.
5. Agri- Waste Hammer Mill can be used by two methods, positive presssure and negative pressure. The picture showed to you is negative press, which means fan blower is installed after cyclone. It is sure that we can make it into positive as per your request.
3. Agri- Waste Hammer Mill Different sizes of sieves can be installed at the bottom of the hammer mill as per the particle size you need.
4. Agri- Waste Hammer Mill key spare parts such as hammer blades are 65mn alloy steel, crushing system is setady, wear resistance, and function is good.
5. Agri- Waste Hammer Mill raw material should be not too wet, if moisture kept between 15-20%, then will be the best. Low moisture, then per hour capacity is more higher, or will be lower
Techinial parameters for Agri- Waste Hammer Mill
Modle |
Power (kw) |
capacity |
Weight|(t) |
Number of hammer board |
Size (mm) |
SG40 |
7.5 |
0.2-0.5 |
0.27 |
12 |
1310*800*1070 |
SG50 |
15 |
0.6-0.8 |
0.45 |
16 |
1380*800*1010 |
SG65*30 |
22 |
0.8-1.2 |
1.1 |
24 |
1500*1000*1100 |
SG65*55 |
37-45 |
1-2 |
1.5 |
48 |
1700*1000*1100 |
SG65*75 |
55-75 |
2-3 |
1.9 |
72 |
2100*1000*1100 |
SG130*100 |
90-110 |
3-4 |
2.3 |
90 |
2400*1000*1100 |
SG130*55 |
130-160 |
5-6 |
5.3 |
108 |
2800*1620*2100 |
SG130*100 |
160-220 |
7-7 |
6.8 |
160 |
3020*1620*2170 |
Picture of Wood grinder/wood hammer mill is packing :
Auxiliary parts of Wood grinder/wood hammer mill
Wood grinder/wood hammer mill on the Fair:
Wood grinder/wood hammer mill is to be delivered
Notifications when using Wood grinder/wood hammer mill
1. Wood grinder/wood hammer mill can be installed with different kinds of sieves, you can choose according to your actual need. If you want to process different size powder, then you need different size sieve,( sieve size:0.8cm, 1cm, 1.2cm. 1,5cm, 2.0cm)
2. Wood grinder/wood hammer mill is high speed rotorying parts, hammer blades must be fixed firmly, avoid hard rawmterial entering into.
3. Wood grinder/wood hammer mill blades are of wear parts, should be checked time to time, when having no edges and conners, reversible or swithcing to use. But the position of hammer blades cant be changed, or will effect balance.
4 If raw material is too big, then should be make into small one to feed in.
Wood grinder/wood hammer mill
