Specifications
PF Impact crusher1.high ratio of crushing
2.cubic final product
3.good wear resistance
4.ISO 9001, CE
Application of PF Impact Crusher machine of stone crusher :
Impact Crusher can crush many kinds of large, medium, small materials such as rock or stone whose
side length is less than 500mm, and compression resistance should not be more than 350Mpa. And The
impact crusher (impactor) is widely used in hydroelectricity, highway, artificial rock, stone and sand,
building material, etc.
Working Principle of the PF impact crusher machine of stone crusher :
When the impact crusher works, the motor drives the rotor rotate with high speed, on the rotor where
installed the hammers. When the materials get into the area which the hammers effect, under the impact
function of the hammer at a high speed, the materials are thrown to the impact device above the rotor
continuously. And then the materials are rebounded from the impact liner to the area where the hammers
effects for being re-crushed. The materials from large to small all to be crushed at the impact chamber
repeatedly.The process won’t stop till the material are crushed to the required size and then discharged
from outlet.
Our PF Impact crusher machine for stone crusher has:
1. Largecapacity: big feed opening, high crushing cavity, suitable for materials with high hardness, large
block, and few stone powers.
2.High ratio of reduction: impact crusher has larger crushing ratio than hammer crusher. It can make full
use of the high-speed impacting energy of the whole rotor.
3. Perfect structure: compact structure, strong rigidity of machine, the rotor has a large rotational inertia
4. Large adjustable range: the gap between impact plate and board hammer can be adjusted, effectively
controlling the discharged material size, with good particle shape.
5.Good wear-resistance:high -chromium board hammer is wear resisting enough to bear strong impact
force.
6.Easy maintenance: keyless connection, easy to maintain, reliable and economical
7. Wide range of choices:we provide different dimensions of product which can meet various needs
Technical Parameter:
| Model | specifications (mm) | Feeding size(mm) | Biggest size of material(mm) | Capacity (t/h) | Motor power(kw) |
| PF-0607 | ø-644*740 | 320*770 | 100 | 10-20 | 30 |
| PF-0807 | ø-850*700 | 400*730 | 300 | 15-30 | 30-45 |
| PF-1008 | ø-1000*800 | 400*830 | 300 | 30-50 | 37-55 |
| PF-1010 | ø-1000*1050 | 400*1080 | 350 | 50-80 | 55-75 |
| PF-1210 | ø-1250*1050 | 400*1080 | 350 | 70-120 | 110-132 |
| PF-1212 | ø-1250*1250 | 400*1300 | 350 | 100-150 | 132-160 |
| PF-1214 | ø-1250*1400 | 400*1430 | 400 | 130-180 | 160-200 |
| PF-1315 | ø-1320*1500 | 860*1520 | 500 | 160-250 | 180-260 |
| PF-1320 | ø-1320*2000 | 860*2030 | 500 | 300-350 | 300-375 |
WELCOME TO VISIT OUR COMPANY!
