Specifications
PEX fine jaw crusher:-Large crushing ratio
-Simple structure&easy maintenance
-produce fine material size
jaw stone crusher machine application:
the stone jaw crusher is widely used for crusher materials which compressive strength less than 350 Mpa, such as limestone, river stone, building materials.
Stone jaw crusher features:
1) with large opening size, high crushing ratio, it's widely used as first crushing during whole stone production plant
2) simple structurer, easy maintenace.
3) durable and hard-wearing jaw plates, can using longer time.
4) reasonable design, working reliable.
Stone jaw crusher working principle:
The PE serial jaw crusher mainly consists of main frame, movable( swing ) jaw, eccentric shaft, toggle plates etc. The electric motor passes power via V-belt pulley to the eccentric shaft to make the movable jaw moves in mesh, therefore, materials in crushing chamber can be crushed.
ISO Certificate New type jaw crusher technical parameters:
| Model |
Size of Feeder Opening (mm) |
Max. Feeding Size (mm) |
Capacity (t/h) |
Motor Power (KW) |
Overall Dimensions (mm) |
Weight (t) |
| PE150×250 | 150×250 | 125 | 1-3 | 5.5 | 896×745×935 | 1.2 |
| PE250×400 | 400×250 | 210 | 5-20 | 15 | 1430×1310×1340 | 2.2 |
| PE400×600 | 600×400 | 350 | 15-50 | 30 | 1700×1732×1653 | 6.8 |
| PE500×750 | 500×750 | 425 | 15-65 | 55 | 2035×1921×2000 | 12 |
| PE600×900 | 900×600 | 480 | 45-110 | 75 | 2290×2206×2370 | 17 |
| PE750×1060 | 1060×750 | 630 | 105-195 | 90 | 2655×2302×3110 | 29 |
| PE900×1200 | 900×1200 | 750 | 90-220 | 110 | 3800×3166×3045 | 50 |
| PEX150×750 | 750×150 | 125 | 5-15 | 15 | 1220×1480×1180 | 3.6 |
| PEX250×750 | 750×250 | 210 | 15-30 | 30 | 1667×1545×1020 | 5 |
| PEX250×1000 | 1000×250 | 210 | 15-50 | 37 | 1964×1550×1380 | 7 |
| PEX250×1200 | 1200×250 | 210 | 20-60 | 37 | 2192×1900×1950 | 8.5 |
| PEX300×1300 | 1300×300 | 250 | 20-70 | 55 | 2400×1930×1747 | 11.6 |
Besides, there are impact crusher, cone crusher, harmmer crusher, roller crusher, in our company, welcome you inquiry any equipment.
Certificate
Customer visit
So far, Hongji machinery had been sold to Russia, Pakistan, Korea, Indonesia, Mexio, Australia, Spain, Ukraine, U.S.A ,South Africa, Arabia and so on.Welcome you visit our company.
Workshop
So far, there are advanced process equipment in our workshop, such as rolling machine, welding machine, boring machine, which can ensure the machinery's quality
After-sell service
1) our engineer will guide and train worker to install and operate equipments, detailed installing drawing will be offered.
2) if there is any problem about equipments during reasonable operation within one year, we will ask engineer to solve problems for you.
