Specifications
1.Material: Q235A and Rubber belt.2.Low carbon, environmental
3.Delivery: 7 days.
4.Small order accepted.
1. Classification of steel cord conveyor belt
Conveyor can be horizontal, tilt and vertical transmission, but also the composition of space transmission lines, transmission lines are generally fixed. Conveyor transport capacity, long-distance, but also in the transportation process while completing a number of process operation, it is widely used. Main belt conveyor, plate conveyor, screw conveyor, bucket conveyor, bucket elevator, overhead conveyors and so on.
2. Work environment of steel cord conveyor belt
Belt conveyor, belt conveyor for conveying bulk density of less than 1.67 / t / cubic meter, easy to dig a powder, granular, small block of low-abrasive materials and bags of materials, such as coal, gravel, sand, cement, fertilizer, and grain. Sent material temperature is less than 60 °C. The form of their captain and assembly can be determined according to user requirements, transmission can be electric drum can also be used with a drive rack drive.
3. Application of steel cord conveyor belt
Songling conveyor is adaptable to both stationary and mobile crushing plants, it is widely used in mining, metallurgical and coal industry to transfer sandy or lump materials, or packaged materials. The transfer system can be one single or multi-conveyors or combined with other transfer equipments according to various transferring requirements. And Songling belt conveyor can be installed horizontally or aslope to meet the needs of different transfer lines.
4.Technical parameters of steel cord conveyor belt
|
Belt Width (mm) |
Belt Length(m) / Power(kw) |
Belt Speed (m/s) |
Capacity (t/h) |
||
B400 |
≤12/1.5 |
12-20/2.2 |
20-25/3 |
0.8-2 |
40-80 |
B500 |
≤12/3 |
12-20/4 |
20-30/5.5 |
0.8-2 |
78-191 |
B650 |
≤12/4 |
12-20/5.5 |
20-30/7.5 |
0.8-2 |
131-323 |
B800 |
≤10/4 |
10-15/5.5 |
15-25/7.5 |
1.0-2 |
278-546 |
B1000 |
≤10/5.5 |
10-20/7.5 |
20-25/11 |
1.0-2 |
435-853 |
B1200 |
≤10/7.5 |
10-20/11 |
20-25/15 |
1.0-2 |
655-1284 |
Note:The technical parameters above are just for your reference. If there is any change, all parameters and overall dimension are subject to operating instructions. Any questions please feel free to contact us.
Welcome to visit our factory!
