High Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore With CE, ISO and IQNET Certificates

High Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore With CE, ISO and IQNET Certificates thumbnail-1
High Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore With CE, ISO and IQNET Certificates photo-1
US$ 8,888 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Ball Mill
Motor Type:
AC Motor
Contact Supplier Request Quote Chat Now
Henan Hongji Mine Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Ball Mill
Motor Type AC Motor
Power(W) 18.5-800kw
Capacity(t/h) 1-130
Place of Origin Henan, China
Brand Name HONGJI
Certification ISO, CE & IQNET
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

ball mill for grinding copper ore:
1)Reduce energy consumption by 30%
2)Improve fineness of discharging
3)ISO, CE, IQNET

Ball Mill for Grinding Copper Ore



Ball mill for Grinding Copper Ore introduction:

Ball mill is the most commonly used grinding equipment, it is widely used in cement,silicate products, new building materials, refractory, fertilizer, non-ferrous metal, glass ceramic and other industries. It mainly grinds various ores and other grind-able materials,the type of the grinding include dry grinding and wet grinding. Ball mill is mainly composed by the components of cylinder, driving big gear ring,end cap,bearing and so on.



Structure Features of ball mill for Grinding Copper Ore:

The ball mill is composed by the feeding device,discharging device,rotating device, transmitting device and some other components. The hollow shaft of the ball mill is made of steel-casting, the liner is detachable, rotary gear hobbing processing with hobbing casting, and the cylinder of ball mill lining with wear-resistant plate, which decide the ball mill of good abrasion resistance. Thus, the ball mill is stable to operate and reliable to work.

High Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET Certificates



Energy-Saving Ball Mill for Grinding Copper Ore Working Principle:

The Energy-Saving Ball Mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

High Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET Certificates



Technical Parameters of Ball Mill for Grinding Copper Ore:



Model

Rotation speed (r/min)

Ball load (t)

Feeding size (mm)

Discharging size (mm)

Capacity (t/h)

Power (kw)

Weight (t)

900*1800

36-38

1.5

≤20

0.075-0.89

0.65-2

18.5

4.6

900*3000

36

2.7

≤20

0.075-0.89

1.1-3.5

22

5.6

1200*2400

36

3

≤25

0.075-0.6

1.5-4.8

30

12

1200*3000

36

3.5

≤25

0.074-0.4

1.6-5

37

12.8

1200*4500

32.4

5

≤25

0.074-0.4

1.6-5.8

55

13.8

1500*3000

29.7

7.5

≤25

0.074-0.4

2-5

75

15.6

1500*4500

27

11

≤25

0.074-0.4

3-6

90

21

1500*5700

28

12

≤25

0.074-0.4

3.5-6

130

24.7

1830*3000

25.4

11

≤25

0.074-0.4

4-10

130

28

1830*4500

25.4

15

≤25

0.074-0.4

4.5-12

155

32

1830*6400

24.1

21

≤25

0.074-0.4

6.5-15

210

34

1830*7000

24.1

23

≤25

0.074-0.4

7.5-17

245

36

2100*3000

23.7

15

≤25

0.074-0.4

6.5-36

210

34

2100*4500

23.7

24

≤25

0.074-0.4

8-43

245

42

2100*7000

23.7

26

≤25

0.074-0.4

8-48

280

50

2200*4500

21.5

27

≤25

0.074-0.4

9-45

280

48.5

2200*6500

21.7

35

≤25

0.074-0.4

14-26

370

52.8

2200*7000

21.7

35

≤25

0.074-0.4

15-28

380

54

2200*7500

21.7

35

≤25

0.074-0.4

15-30

380

56

2400*4500

21

30

≤25

0.074-0.4

8.5-60

320

65

2700*4000

20.7

40

≤25

0.074-0.4

12-80

400

94

2700*4500

20.7

48

≤25

0.074-0.4

12-90

430

102

3200*4500

18

65

≤25

0.074-0.4

25-130

800

137



High Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET CertificatesHigh Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET CertificatesHigh Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET CertificatesHigh Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET CertificatesHigh Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET Certificates

High Efficiency and High Quality Energy-saving Ball Mill for Grinding Copper Ore with CE, ISO and IQNET Certificates
