Specifications
XJK gold ore separaton equipment1.improve quality of 4-6%
2. improve recovery rate 8%
3. increase output 12%
Mineral dressing is advantage of Hongji, there are professional enginner who had been this field for 30 years, unique design can be offered according to raw material features and required. There are flotation machine, magnetic separate, shaking table, classifier and so on. welcome you inquiry us.
Flotation machine application:
Flotation machine is widely applicable for coarese separation, fine separator and reverse flotation of nonferrous metals like copper, lead, zinc,nickel and molybdenum as well as ferrous metal and non-metallic minerals.
Flotation machine working principle:
When flotation machine works, slurry is inhaled from the bottom of the trough to the space between impellers. Meanwhile, the low_pressure air send by fan is sent to this area through the air distributor in the hollow shaft. After sufficient mixing, the slurry is pushed out by the impeller, and then goes to the whole trough. When the froth rises to the stable level, after the enrichment processing, froth overflows to the froth trough from the overflow weir. Another part of ore slurry flows to lower part of impeller for the re_mis with air. The remained slurry flows to the next trough until becomes residue.
flotation machine features:
Compared with common flotation machine, this SF flotation machine has the following advantages:
Improve grade 4-6%;
Improve recovery rate 8%
Improve capacity 12%
Main Technical Parameters of XJK Flotation Machine:
| Model | Valid volume m3/slot | Impeller diameter (mm) | Capacity (m3/min) | Impeller rotation speed (r/min) | Scraper rotation speed (r/min) | Motor | Dimension 4-slot machine (mm) | Weight t/slot | |
| Model | Power (kw) | ||||||||
| XJK-0.13 | 0.13 | 200 | 0.05-0.16 | 600 | 17.5 | Y90L-4 | 1.5 | 2100865900 | 0.35 |
| XJK-0.23 | 0.23 | 250 | 0.12-0.28 | 500 | 17.5 | Y90L-4 | 1.5 | 262511301290 | 0.41 |
| XJK-0.35 | 0.35 | 300 | 0.15-0.5 | 470 | 17.5 | Y100L1-4 | 2.2 | 301213501320 | 0.45 |
| XJK-0.62 | 0.62 | 350 | 0.3-0.9 | 400 | 16 | Y100L2-4 | 3 | 380015001550 | 0.85 |
| XJK-1.1 | 1.1 | 500 | 0.6-1. 6 | 330 | 26 | Y132M-6 | 5.5 | 468018201950 | 1.4 |
| XJK-2.8 | 2.8 | 600 | 1.5-3.5 | 280 | 26 | Y160L-6 | 11 | 775026002700 | 2.43 |
Certificate
Customers visit
So far, Hongji machinery had been sold to Russia, Pakistan, Korea, Indonesia, Mexio, Australia, Spain, Ukraine, U.S.A ,South Africa, Arabia and so on.Welcome you visit our company.
Workshop
So far, there are advanced process equipment in our workshop, such as rolling machine, welding machine, boring machine, which can ensure the machinery's quality
