Hot Gas Station Manufacture/ Coal Gasifier With ISO Approved

Hot Gas Station Manufacture/ Coal Gasifier With ISO Approved photo-1
US$ 7,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
Hongji
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao shanghai tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name Hongji
Model Number QM0.8
Power(W) <27
Weight 3.5-37.6T
Certification ISO.CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas
Type Other, Blast Furnace

Specifications

Coal Gas Generator features:
1) Convenient to remove slags;
2) Easy to operate and maintain;
3) enviromental protection;

Coal Gasifier Introducion:



Coal gasifier is Electric start, water-cooled, four-stoke, direct injection,compact design with low noise, heavy load durable,low exhaust emission. environmental friendly

Our coal gasifier uses air and vapor as the gasifying agents to produce mixed gas. It is suitable for gasifying coking coal, hard coke, etc. and is widely used in machinery, metallurgy, chemistry, glass, building materials, food, textile and light industries.



Coal Gasifier Advantages :


Our  coal gasifier features low investment, good applicability, convenient use, easy operation, etc. Compared with direct coal burning, coal gasifier can save 20% of the fuel. Compared with oil furnace, coal gasifier can save more than 60% of the energy. Our coal gasifier is environment-friendly with its heat efficiency and good dust and smoke removal effect.



Coal Gasifier Working Principle:





Hot Gas Station Manufacture/ Coal Gasifier with ISO approved




Solid coal can be gasified into inflammable gases through vapor media. This coal gas is then roughly de-dusted and conveyed through a conveying pipe to burn at a nozzle. The heat produced is used to heat the thermal furnace. With the gas as the burning material, the temperature is even on the furnace. Our single stage coal gasifier is widely used as steel rolling furnace, annealing furnace, forging furnace, steel pipe furnace, glass furnace, aluminum furnace, melting furnace, cooper furnace, pottery furnace, etc.



Coal Gasifier Technical Parameters:



Model(mm) QM0.8 QM1.0 QM1.2 QM1.5 QM1.6 QM1.8 QM2.0 QM2.4 QM2.6 QM3.0 QM1.5
Chamber diameter(mm) 800 1000 1200 1500 1600 1800 2000 2400 2600 3000 1500
Hearth active surface 0.5 0.785 1.13 1.77 2.01 2.54 3.14 4.52 5.31 7.07 1.77
Suirable fuel weak coherent gas carbon,anotherracite,burnt carbon
Fuel granularity(mm) 25-80
Fuel consumption quantitykg/h 40-100 70-140 120-190 160-350 350-460 500-600 500-720 700-1040 850-1200 1700-2000 1800-2200
Gasifying agent Air ,steam
Gas yield(Nm³/h) 140-350 245-490 420-670 560-1200 1200-1600 1500-2100 1750-2500 2500-3600 3000-4300 6000-7000 6500-7500
Gas calorific valu(Kj/Nm³) 5020-5670 5020-6000
Water jacket heating area(m2) 4.02 5.02 6.78 10.37 11.06 12.44 17.58 21.87 23.69 30.16 10.37
Steam output kg/h 60 80 130 200 220 260 350 420 600 840 200
Gas outlet temperature(°C) (400-500)Plants related with the coal (400-500)Plants related with the coal
Gas outlet pressure(Pa) 1000 980-1470 1470-1960 980-1470
Gas exportation diameter(mm) 219 325 325 426 426 529 630 720 820 1020 426
Air pressure(Pa) 3000 4000 3000
Saturated air temperature(°C) 50-60 50-65
Ashpan rotational speed(r/h) 0.177-1.77
Equipment gross weight(t) 3.5 4.5 5 7.5 10 20 23.4 29.8 32 37.6 16
Complete machine power(kw) 6 6 6 7 8 10 14 20 20 27 7
Tuyere diameter(mm) 108 108 140 165 219 325 325 426 426 426 219



Product Pictures:



Hot Gas Station Manufacture/ Coal Gasifier with ISO approved Hot Gas Station Manufacture/ Coal Gasifier with ISO approved



Certificate and Honour:

Hot Gas Station Manufacture/ Coal Gasifier with ISO approved

Hot Gas Station Manufacture/ Coal Gasifier with ISO approved
