Urea Pump115V-230V for IBC Systems

Name: Urea Pump115V-230V for IBC Systems
Brand: SINGFLO
SKU: 139205271
Availability: InStock

Urea Pump115V-230V for IBC Systems thumbnail-1

Urea Pump115V-230V for IBC Systems photo-1

US$ 80 - 100 MOQ: 10 Sets

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

SINGFLO

Model Number:

HV series

Contact Supplier Request Quote Chat Now

Xiamen Youme Electric Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

china port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name SINGFLO

Model Number HV series

Theory Reciprocating Pump

Structure Diaphragm Pump

Usage Water

Power Electric

Standard or Nonstandard Standard

Fuel Other, electric

Pressure Low Pressure

Application Other, transfer industrial liquid

Specifications

Urea pump115V-230V for IBC systems
1Continuous working with low temperature
2)Max flow:30~50LPM
3)Pressure max: 25PSI

Urea pump115V-230V for IBC systems

Product Description

specification:

PUMP Design: 5 chamber diaphragm

Motor Design: Permanent magnet DC

Voltages: 12, 24VDC/115V,230VAC

Pump Body: Aluminium

Diaphragm: Viton

Check valves: Viton

Max. Flow Rate: 30lpm~50lpm

Max. Pressure: 25PSI (2BAR)

Liquid Temp: 40°F (5°C)MIN; 140°F (60°C)MAX

Duty cycle: Continuous work with self-priming

Gross Weight: 5.5kg per DC pump 6.5kg per AC pump

Certifications: CE

Port Size inlet/ outlet: 3/4” 1''

AC Model:

DC Model:

DC AC industrial ablue pump Technical data:

DC MOUNTING

The HV Series pumps are self-priming and may be located above or below the water supply in a dry location. To vertically mount these units, it is best to do so with the motor on top. This will prevent water dripping on the motor in the event of a leak. Place pump on a solid surface and secure with four mounting screws; be careful not to compress the rubber grommets, which act as vibration dampers.
