Product Details
| Place of Origin | United States | Brand Name | Alien | |
| Model Number | ALN-9745 |
Product Description
Product Name: Original Alien H3/H4 wet/dry inlays uhf rfid tags for books
Product Model: ALN-9745
Product Applications:
Book spines
Small package labels
Doors
Narrow form factor assets
Cigarette boxes
Shipping labels
Product Features:
The Alien Technology® ALN-9745 “SlimLine” RFID inlay is a specialized thin-form factor highperformance tag. The ALN-9745 brings all the Higgs™ 4 advantages to a tag that can fit in
extremely narrow confined spaces.
Product Specifications
Antenna Width | 3.701” [94.0mm] |
Antenna Length | 0.228” [5.8mm] |
Web Width | 4.252” [108.0mm] |
Web Pitch | 0.625” [15.875mm] |
| Core Width
| 4.252"[108mm] |
Core ID | 6” [152.4mm]* |
Core Material | Fiberboard |
Interleaf Material | Paper |
Inlays per Roll | 20,000 Nominal |
Maximum Roll OD | < 12” [304.8mm] |
Roll Labeling Data | Roll #, Quantity |
Wet Inlay
Inlay Width | 3.827” [97.2mm] |
Inlay Length | 0.354” [9mm] |
Web Width | 3.95” [99.7mm] |
Web Pitch | 0.625” [15.875mm] |
Core Width | 3.953” [100.4mm] |
Core ID | 6” [152.4mm]* |
Core Material | Fiberboard |
Inlays per Roll | 20,000 Nominal |
Maximum Roll OD | < 16” [406.4mm] |
Roll Labeling Data | Roll #, Quantity |
White | TT Printable White Film Only |
Overlay Adhesive | General Purpose Permanent |
Inlay Adhesive | General Purpose Permanent |
Adhesive Application Temperature | > +25ºF [-4ºC] |
Adhesive Service Temperature | -40ºF to +200ºF [-40ºC to +93.3ºC] |
Release Liner | 40# SCK |
RFID
Protocols Supported | ISO/IEC 18000-6C EPCglobal Class 1 Gen 2 |
Integrated Circuit | Alien Higgs-4 |
EPCglobal Certificate | 950110126000001084 |
Operating Frequency | 840--960 MHz |
EPC Size | 128 Bits |
User Memory | 128 Bits |
TID | 32 Bits |
Unique TID | 64 Bits |
Access Password | 32 Bits |
Kill Password | 32 Bits |
