automatically vertical continuous feeding bucket elevator equipment
automatically vertical continuous feeding bucket elevator equipment is the new cute machine which we designed according to the customers' actual needs.With universal wheel and lock it is easily move or stop on the ground surface. With small cubage,it is ideal feeding machine for silo or filling bagging machine.
|
automatically vertical continuous feeding bucket elevator equipment is made up of operation device, top part with driving device, and down part with tensioning device.
2. top part with driving device
3. down part with tensioning device
|
automatically vertical continuous feeding bucket elevator equipment adopts material flow trough feeding way. when the material feed into the bucket, and belt bucket willl lift to the machine top and than automatically discharging the material by the gravity function.
Customized Design and Color is supported
Machine In our Workshope
Related Spareparts(canvas belt with bucket and bot screw)
Steel Plate Chain
|
| Model | TD160 | TD250 | TD315 | TD400 | ||||||||||||
| Hopper type | Q | H | ZD | SD | Q | H | ZD | SD | Q | F | ZD | SD | Q | H | ZD | SD |
| Capacity (m3/h) | 5.4 | 9.6 | 9.6 | 16 | 12 | 22 | 23 | 35 | 17 | 30 | 25 | 40 | 24 | 46 | 41 | 66 |
| Hopper width (mm) | 160 | 250 | 315 | 400 | ||||||||||||
| Hopper volume (L) | 0.5 | 0.9 | 4.2 | 1.9 | 1.3 | 2.2 | 3.0 | 4.6 | 2 | 3.6 | 3.8 | 5.8 | 3.1 | 5.6 | 5.9 | 9.4 |
| Hopper distance (mm) | 280 | 350 | 360 | 450 | 400 | 500 | 480 | 560 | ||||||||
| Belt width (mm) | 200 | 300 | 400 | 500 | ||||||||||||
| Hopper speed (m/s) | 1.4 | 1.6 | 1.6 | 1.8 | ||||||||||||
| Max granule(mm) | 25 | 35 | 45 | 55 | ||||||||||||
| Model | TD500 | TD630 | TD160 | TD250 | TD350 | TD450 | ||||||||||
| Hopper type | Q | H | ZD | SD | H | ZD | SD | Q | S | Q | S | Q | S | Q | S | |
| Capacity (m3/h) | 38 | 70 | 58 | 92 | 85 | 89 | 142 | 4.7 | 8 | 18 | 22 | 25 | 42 | 50 | 72 | |
| Hopper width (mm) | 500 | 630 | 160 | 250 | 350 | 450 | ||||||||||
| Hopper volume(L) | 4.8 | 9 | 9.3 | 15 | 14 | 14.6 | 23.5 | 0.65 | 1.1 | 2.6 | 3.2 | 7 | 7.8 | 14.5 | 15 | |
| Hopper distance (mm) | 500 | 625 | 710 | 300 | 400 | 500 | 640 | |||||||||
| Belt width (mm) | 600 | 700 | 200 | 300 | 400 | 500 | ||||||||||
| Hopper speed (m/s) | 1.8 | 2 | 1 | 1.25 | 1.25 | 1.25 | ||||||||||
| Max granule (mm) | 60 | 70 | 25 | 35 | 45 | 55 | ||||||||||
| The loading and shipping site of automatically vertical continuous feeding bucket elevator equipment. |
| We have other series lifting or vertical conveying equipment for your choice. 1.NE Series bucket elevator
2. TH Series bucket elevator
3. Vertical vibrating screw elevator
|
IF you can't finalize what you are looking for, Just contact us directly by the following information. The professional technical team and sales team will try our best to find the solution for all your problems.
