Mingyang brand High efficient Best wood shaving machine with Animal bedding
Brief introduction-- wood shaving machine
1.wood shaving machine is an ideal machine, which for preparing with producing wood powder.
2.The raw material gets into the machine from feeding port, through the cutter to the crushing room, under the effect of the mutual striking hammers, the material is being crushed.
3.The wood shavings are the same as the ones from furniture factory.
4.The machine can process timber,branch and other materials into wood chips,with less investment and low energy consumption, high efficient, good economic returns,easy maintenance.
5.The spare part of the machine completely adopt quality material, outsourcing parts adopting domestic optimal product,the whole machine’s quality is reliable, long-lived.
6.The equipment can also be used as raw materials, which for produce edible mushrooms, shaving board, sawdust board and dense board.
NOTE: The productivity can vary a food according to type and moisture content, as well as the size of the holes in the sieve.
Raw material-- wood shaving machine
The wood shaving machine are for grinding the Bio-mass like straw, coconut shell , stalk and wood chip, tree branch and forest waste to be powder of less than 3-5mm, which is right size before pelletizing and briquette. It is also ideal machine for farming material like dry or fresh seeding of yam, peanut, rice and other plants, husks, maize, wheat, beans of all.
Application-- wood shaving machine
1.it can be used for shaving board, Shaving board plant, board mill, paper-making plant
2.Raw material of wood pulp paper in paper-making plant
3.Shipping company used as fillings for shipping fragile things.
4.As the biological fuel
5.Used as animal beds fillings in farm plant for cow, pig, horse, sheep or all kinds of animals
Specification-- wood shaving machine
Model |
9BHN-140 |
Max. log input length |
140 cm |
Max. log input width |
45 cm |
Cutterheads |
4 pcs. |
Knives per cutterhead |
6 pcs. |
Speed of cutterhead |
4500 rpm. |
Diameter of cutterhead |
140 mm |
Drive capacity |
37KW |
Shaving depth |
1mm - 5mm |
Travelling distance of carriage |
2200 mm |
Feeding speed (hydraulic) |
0.1 - 0.25 m/sec. |
Dimension ( W x L x H ) |
115 x 515 x 180 cm |
Total weight |
2850 kg |
We also have small capacity wood shaving machine,
the detailed information is below:
Model |
9BH-420 |
9BH-600 |
9BH-800 |
Output(kg/h) |
400 |
800 |
1200 |
Inlet size(mm) |
160*80 |
200*120 |
230*230 |
Knife number |
4 |
4 |
8 |
The knife length(mm) |
90 |
150 |
150 |
Power(kw) |
7.5 |
15 |
30 |
Outsize(m) |
1.2*0.5*0.8 |
1.5*0.7*0.85 |
1.8*0.85*1.15 |
Weight(kg) |
150 |
280 |
500 |
Packing pictures of the wood shaving machine
This shaving blade machine can pack with wooden case. Like the pictre below
The pre-sales service:
To provide you with the project and process design, make suitable plan for you, or design and manufacture the products according to your special needs.
The sales of service:
To accompany you to complete the equipment inspection and acceptance, assists to draft the construction scheme an detailed process.
The after-sales service:
Our company could send the engineer to guide the installation of equipment and the commissioning of the machine.
About us:
Gongyi Xiaoyi Mingyang Machinery Plant is located in Zhengzhou City, which is the biggest manufacturing base of charcoal making machinery.And we are the one of the earliest and largest manufacturers of renewable fuel & energy equipments and related machinery.
After 15 years development, now our company becomes an independent economic entity with the integration of science, engineering and trading department. our products and are widely accepted in both domestic and world market, and also exported to more than 30 countries, such as England, Russia, Sweden, Poland, Iran, Sudan, South Malaysia, Indonesia, Vietnam, etc.
We have got many certification such as CE,ISO9001, BV and so on
