400KG per hour output WPC Foam Board Extrusion Line for furniture board
1. WPC Foam Board Extrusion Line description
The extrusion line is composed of conical twin screw extruder, die, vacuum calibration unit, hall-off unit and so on. Our company can provide the formula and all the processing techniques. This machine
has the features of high output, stable extrusion, high foaming, smooth and wearable surface.By equipping
with the printing machine, laminating machine or hot stamping machine, this machine can produce different
kinds of artificial wood products, so that this machine has a very wide application range.
2. WPC foam board extrusion line main technical parameters:
| No. | Item | Descriptions |
| 1 | Products material | PVC + wooden powder + other additives |
| 2 | Products thickness | 5-25mm |
| 3 | Extrusion capacity(max) |
400kg/h (capacity varies with the density change) |
| 4 | Total installed power |
215kw (Including mould heating power) |
| 5 | Tractor line speed range | 0.1—1.2M/min |
| 6 | Products max width | 1220mm×2440(Length can be adjusted) |
| 7 | Production line dimensions |
about 24000×2480×2200 mm |
WPC Foam Board Extrusion Line Main technical parameter
| Model | unit | SJZ80/156 | SJZ92/188 |
| Screw dia. | MM | 80/156 | 92/188 |
| Screw quantity | Piece | 2 | 2 |
| Rotational speed | r/min | 1-38 | 1-32.9 |
| Main extruder power | KW | 55 | 110 |
| Heating power(approx) | KW | 36 | 45 |
| Extrusion output | Kg/h | 100-400 | 400-500 |
| Max. Thickness of board | mm | 25 | 50 |
| Board wide | Mm | 1220 | 1220-1680 |
