Specifications
1,ready mix aggregate plants2, with full automatic control
3. Guarantee period: one year
ready mix aggregate plants with low price and high effective
HZS50 ready mix aggregate plants with low price and high effective is composed of material supply, batching system, mixing, electrical control and steel structure.
Main features of ready mix aggregate plants with low price and high effective
1. This ready mix concrete plant for sale adopts JS1000 concrete mixer, it has good mixing quality and high efficiency.
2. Our concrete mixing plant is measuring nicety and high produce efficiency.
3. It adopts the electrical weigher to measure all the aggregate, cement, water, liquid additive.
4. The greasing system, which is controlled by central control system, lubricates the greasing points at the fixed position, fixed time and fixed quantity.
Main Technical Parameters of ready mix aggregate plants with low price and high effective
Type |
HZS25 |
HZS35 |
HZS50 |
HZS75 |
HZS100 |
HZS150 |
||
|
Theoretical Production (m3/h) |
25 |
35 |
50 |
75 |
100 |
150 |
||
Mixer |
Type |
JS500 |
JS750 |
JS1000 |
JS1500 |
JS2000 |
JS3000 |
|
|
Power (kw) |
18.5 |
30 |
2X22 |
2X30 |
2X37 |
2X55 |
||
|
Discharging Capacity (m3) |
0.5 |
0.75 |
1 |
1.5 |
2 |
3 |
||
|
Aggregate Diameter (mm) |
60 |
60 |
60 |
80 |
80 |
80 |
||
Aggregate Bin (m3) |
10 |
10 |
13 |
13 |
20 |
30 |
||
|
Belt Conveying Capacity (t/h) |
260 |
280 |
300 |
450 |
550 |
650 |
||
Weighing Accuracy |
Aggregate (kg) |
1000±2% |
1000±2% |
1200±2% |
2000±2% |
2200±2% |
3000±2% |
|
|
Cement (kg) |
350±1% |
450±1% |
600±1% |
1000±1% |
1200±1% |
1800±1% |
||
|
Fly Ash (kg) |
280±1% |
300±1% |
300±1% |
400±1% |
400±1% |
500±1% |
||
|
Water (kg) |
300±1% |
300±1% |
350±1% |
500±1% |
500±1% |
800±1% |
||
|
Additives (kg) |
25±1% |
25±1% |
30±1% |
50±1% |
50±1% |
80±1% |
||
Total Power (kw) |
55 |
65 |
85 |
115 |
130 |
170 |
||
Discharging Height (m) |
≥3.8 |
≥3.8 |
≥3.8 |
≥3.8 |
≥3.8 |
≥3.8 |
||
Structure of the ready mix aggregate plants with low price and high effective
Delivery picture
