USB 13.56mhz Nfc Reader With Free SDK

Name: USB 13.56mhz Nfc Reader With Free SDK
Brand: Asiantag/OEM
SKU: 139123455
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Asiantag/OEM

Model Number:

AT-13.56mhz nfc reader

Shenzhen Asiantag Electronics Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Asiantag/OEM

Model Number AT-13.56mhz nfc reader

Specifications

13.56mhz nfc reader
1. Power on USB
2.Portable,0.25kg
3. ISO14443A
4. EM-ID 125 KHz/13.56Mhz

13.56mhz nfc reader with free SDK

Dimensions	98 mm (L) x 65 mm (W) x 12.8 mm (H)
Weight	70 g
Interface	USB Full Speed
Operating Distance	Up to 50 mm (depends on the tag type)
Supply Voltage	Regulated 5V DC
Supply Current	200mA (operating); 50mA (standby); 100mA (normal)
Operating Temperature	0-50 °C
Operating Frequency	13.56 MHz
Smart Card Interface Support	ISO14443 Type A & B Mifare FeliCa 4 types of NFC (ISO/IEC18092) tags
Compliance/Certifications	ISO 14443, CE, FCC, KC, VCCI, PC/SC, CCID, RoHS, USB Full Speed Microsoft WHQL: 2000, XP, Vista, 7, 8, Server 2003, Server 2008, Server 2008 R2, Server 2012
Operating System Support	Win98, Win ME, Win NT 4.0, Win 2000, Win 2003, Win 2003 R2, Win XP, Win Vista, Win 2008, Win 7, Win 8 Win 2003 x64, Win 2003 R2 x64, Win XP x64, Win Vista x64, Win 2008 x64, Win 2008 R2 x64, Win 7 x64, Win 8 x 64, Win 2012 x64 Windows CE 5.0 and 6.0 Mac Linux Android 3.1 and above
