Mining Machine large capacity rock crusher machine /crusher rock hammer YA circular vibrating screen
Factory directly supply
YA series Vibrating Screen is of multiple layers and vibrating circularly .It is of long screen line, correct to screen in all kinds of specification products. Our Vibrating Screen adopts the barrel type of eccentric block to adjust the swing .It is also of reliable structure ,strong exiting force ,high screening efficiency ,low vibrating noise ,long durability ,convenient maintenance, safe operation, etc. It is widely used for screening in mines, building material, transportation, energy sources, chemical industry, etc.
YA series Vibrating Screen:
It uses eccentric block to produce strong exciting force. Crossbeam and the main body of the screen are connected with high strength screw bolts. So they have the features of simple structure and easy maintenance. It adopts tire clutch with capability of flexible connection and stable operation. It adopts the structure of small amplitude, high frequency, large obliquity to make the screen hold the capability of high efficiency, large handling capacity, long life span, low consumption and noise.
Model |
Layer of |
Size of Sieve |
Max . Feeding Size (mm) |
Capacity (m3/h) |
Double |
Model of Motor |
Motor Power (kw) |
Screen (mm) |
Weight (t) |
Dimension (mm) |
2YA1237 |
2 |
3-50 |
300 |
10-80 |
6-8 |
Y160M-4 |
11 |
1200×3700 |
3.6 |
4600×1900×1200 |
3YA1237 |
3 |
3-50 |
300 |
10-80 |
8 |
Y160M-4 |
11 |
1200×3700 |
3.9 |
4730×1900×1650 |
4YA1237 |
4 |
3-50 |
300 |
10-80 |
8 |
Y160M-4 |
11 |
1200×3700 |
4.5 |
4900×1900×2150 |
2YA1548 |
2 |
3-100 |
300 |
22-160 |
8 |
Y160L-4 |
15 |
1500×4800 |
4.6 |
5720×2260×1200 |
3YA1548 |
3 |
3-100 |
300 |
22-160 |
8 |
Y160L-4 |
15 |
1500×4800 |
5.1 |
5900×2260×1650 |
4YA1548 |
4 |
3-100 |
300 |
22-160 |
8 |
Y160L-4 |
15 |
1500×4800 |
5.6 |
6050×2260×2100 |
2YA1848 |
2 |
3-100 |
300 |
32-276 |
8 |
Y180M-4 |
18.5 |
1800×4800 |
5.35 |
5720×2560×1200 |
3YA1848 |
3 |
3-100 |
300 |
32-276 |
8 |
Y180M-4 |
18.5 |
1800×4800 |
6 |
5900×2560×1650 |
4YA1848 |
4 |
3-100 |
300 |
32-276 |
8 |
Y180M-4 |
18.5 |
1800×4800 |
6.65 |
6050×2560×2100 |
2YA1860 |
2 |
3-100 |
300 |
65-586 |
8 |
Y180M-4 |
22 |
1800×6000 |
6 |
6920×2560×1200 |
3YA1860 |
3 |
3-100 |
300 |
65-586 |
8 |
Y180M-4 |
22 |
1800×6000 |
6.6 |
7100×2560×1650 |
4YA1860 |
4 |
3-100 |
300 |
65-586 |
8 |
Y180M-4 |
22 |
1800×6000 |
7.2 |
7250×2560×2110 |
2YA2160 |
2 |
3-100 |
300 |
81-720 |
8 |
Y200L-4 |
30 |
2100×6000 |
10.1 |
7020×3090×1320 |
3YA2160 |
3 |
3-100 |
300 |
81-720 |
8 |
Y200L-4 |
30 |
2100×6000 |
11.3 |
7160×3090×1780 |
4YA2160 |
4 |
3-100 |
300 |
81-720 |
8 |
Y200L-4 |
37 |
2100×6000 |
12.5 |
7320×3090×2230 |
Factory directly supply hammer to break rock
MINGSHUN PC series Hammer Crusher with high crushing ratio and high efficiency. Our hammer crusher has reliable mechanical structure, high productive and favorable applicability.
Hammer crusher are applicable for various hard and fragile materials, such as limestone, coal, salt, alum, brick and tile, etc. The crushing compression strength of material should not be in excess of 150Mpa. Hammer crusher is mainly used in industries of cement, coal separation, building material and compound fertilizer, etc.
insists on providing clients with overall solution from equipment recommendation to debugging and installation, worker training, technical support and maintenance.
After-sales support service
We will send a professional and high levels installation engineer team at the same time to the destination of the product. In order to supply you a full range of products installation service. For some typical problems, our rigorous installed engineers also will do some certain installation debugging training.etc
