[Handy-Age]-Heavy Duty Lathe (080/0120/0160) (MW0700-049)

Name: [Handy-Age]-Heavy Duty Lathe (080/0120/0160) (MW0700-049)
Brand: Handy-Age
SKU: 139094121
Availability: InStock

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Turning Center

CNC or Not:

Normal

Handy-age Industrial Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

To be advised

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Turning Center

CNC or Not Normal

Place of Origin Taiwan, China

Brand Name Handy-Age

Model Number MW0700-049

Item: Heavy Duty Lathe (080/0120/0160) (MW0700-049)

Specification

MODEL : MW0700-049		080	0120	0160
Nominal Size	Swing over Bed	760mm(30")
	Swing over Cross Slide	500mm(19-3/4")
	Height of Center	380mm(15")
	Distance between Center	2033mm(80")	3050mm(120")	4050mm(160")
Bed	Width of Bedway	485mm(19")
	Total Length of Bed	3320mm(130")	4380mm(172")	5470mm(215")
	Swing over Gap	970mm(38-1/4")
	Length of Gap	515mm(20-1/4")
	Width in front of Face Plate	340mm(13-3/8")
Spindle	Spindle Nose Mounting	D1-11" Camlock
	Spindle Bore	105mm(4-1/8")
	Taper of Spindle Bore	M.T.#5 (with Center Sleeve)
	Number of Spindle Speeds	18 steps (forward & reversed by magnetic clutch control)
	Range of Spindle Speeds	10-1200RPM (with magnetic brake)
Tail Stock	Total Travel Of Tailstock Barrel	195mm(6-5/8")
	Taper in Tailstock Barrel	M.T.#5
	Diameter of Barrel	80mm(3-1/8")
Tool Slide	Total Travel of Cross Slide	375mm(14-3/4")
	Total Travel of Top Slide	225mm(9")
	Max. Size Cutting Tool	28mm(1-1/8")
Threads	Lead Screw Diameter & Pitch	Dia. 38mm Pitch 12mm 2 TPI
	Inch Threads	1/4-80 TPI (60)
	Metric Pitches	0.2-112mm (60)
	Diametrical Pitches	1-240 D.P.(55)
	Module Pitches	0.05-28 M.P. (55)
Feeds	Feed Rod Diameter	38mm(1-1/2")
	Ranger of Longitudial Feeds	0.040-5.000mm/Rev. 0.0015-0.20in/Rev. (40)
	Range of Cross Feeds	0.015-4.000mm/Rev. 0.0006-0.15in/Rev. (40)
Motor	Main Spindle Motor	15 HP 11KW
	Coolant Pump Motor	1/8HP 0.1KW
Weight & Packing Size	Machine Net Weight	3800Kgs	4300Kgs	4800Kgs

Automatic forced lubrication in headstock is moved by a direct motor drive lubrication gear pump, and oil tank is equipped in the floor stand to minimize the cooling of oil
Heavy duty geared head, hardened and ground gears
15HP main spindle motor
Quick-change universal gearbox for inch, metric, DP, MP,threading and multiple thread, all function without any change gears
Four-way rapid carriage movement
Automatic lubrication in saddle and apron assembly
Adjustable oveload clutch in apron to ensure proper cutting load
2 speed tailstock barrel
19"(485mm) wide bed ways, induction hardened and ground
Swing over Bed: 760mm(30")
Distance between Center: 2033mm(80"), 3050mm(120"), 4050mm(160")
Swing over Gap: 970mm(38-1/4")
Spindle Bore: 105mm(4-1/8")
The product pictures are for your reference only: final spec & accessories based on formal quotation
