[Handy-Age]-High Precision Vertical Milling Machine (MW0800-044)

[Handy-Age]-High Precision Vertical Milling Machine (MW0800-044) thumbnail-1
[Handy-Age]-High Precision Vertical Milling Machine (MW0800-044) thumbnail-2
[Handy-Age]-High Precision Vertical Milling Machine (MW0800-044) photo-1
[Handy-Age]-High Precision Vertical Milling Machine (MW0800-044) photo-2
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Taiwan, China
Brand Name:
Handy-Age
Contact Supplier Request Quote Chat Now
Handy-age Industrial Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
To be advised
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Taiwan, China
Brand Name Handy-Age
Model Number MW0800-044
Type Vertical
CNC or Not Normal
Power(W) Please refer to the specifications table
Dimension(L*W*H) 1740x 1540x 2330mm
Weight optional
Warranty 1 year only starting from shipping date

Item: High Precision Vertical Milling Machine (MW0800-044)



Features

  • Max. Table Load: 350-400 kgs
  • X,Y Axes Lead Screw
  • Hardened and ground slide ways assures that the table will stay where it belongs
  • Gear box feed to maintain powerful machining and end milling, and make working more efficiently
  • The very wide saddle 910mm keeps table movement smoothly in all directions to prevent from any deformation and allowance occurred

Description

  • Milling Machine of A model: with Step Speed Head; B model: Variable Speed Head
  • Solid construction, made of meehanite cast iron
  • Made in Taiwan with accurate performance

Specification

ITEMS MW0800-044A MW0800-044B
TABLE WORKING SURFACE 1270x 300
T SLOT (WxNo.xPITCH) 16x 3x 80
TRAVEL XxYxZ-MANUAL 930x 400x 450
XxYxZ-AUTO 920x 380x 450
FEED LONG./MIN. 22-384 (6 STEPS)
LONG. RAPID TRAVERSE/MIN. 1250
VERTI. RAPID TRAVERSE/MIN. 430
SPINDLE SPINDLE NOSE N.S.T. 40
STEPS 10 INFINITELY VARI.
SPINDLE SPEED RPM 70-3600 80-3800
SWIVELLING ANGLE 45° (R&,L)
QUILL TRAVEL 127
QUILL FEEDS/REV. 0.04/0.08/0.15
SPINDLE NOSE TO TABLE 45-495
SPINDLE CENTER TO COLUMN 130-550
CROSS TRAVEL OF RAM 420
HORIZONTAL ROTATION OF RAM 360°
MOTOR VERTICAL SPINDLE 5HP-4P 5HP-4P
FEED LONG. 3/4HP-4P
RAPID VERTICAL 1/2HP-4P-1/10
COOLANT PUMP 1/8HP-2P
SIZE MACHINE (LxWxH) 1740x 1540x 2330mm
NET WEIGHT (KGS) 1650 1700
  • Standard Accessories:
    • Coolant equipment
    • Long. gear box feed
    • Slide way auto lub. Pump
    • Table elevating motor
  • Optional Functions:
    • X, Y Axes Ball Screw with inverter movement
    • Long. Ball Screw Movement
    • X Axis feed Motor: 1HP-2P/4P
  • The product pictures are for your reference only: final spec & accessories based on formal quotation
