170hp Bulldozer With WD Engine U and V Shape Blade

Name: 170hp Bulldozer With WD Engine U and V Shape Blade
Brand: VOLT
SKU: 139077003
Availability: InStock

US$ 50,000 - 50,000 MOQ: 3 Sets

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

VOLT

Model Number:

VT165

Beijing Taishan Guotai Import Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingao/Tianjin/Shanghai/Canton

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name VOLT

Model Number VT165

Condition New

Moving Type Crawler Bulldozer

Machine Weight 17000kg

Dimension(Long * Breadth * High) 6366x3388x3100mm

After-sales Service Provided Overseas service center available

170hp bulldozer with WD engine U and V shape blade

Features:

1. New blade is more durable and capacious.

2. The Alarming and Monitoring system are high efficiency and reliable.

3. Reliable manual-operated spool valve and external mounted multi-valve for easy to maintain.

4. Adopted the model NTA855-C280 CUMMINE engine, which has strong power and torque output ,low fuel consumption, reliable controls.

5. Hydraulic power transmission, automatic speed change, shifting the gear without stop the vehicle.

6. Three-element, single stage and single phase torque convertor, which has high efficiency and larger capacity.

Specifications

Type		VT165
Engine	Model	WD10G178E25/SC11cb184G2B1
	Type	In-line,water cooling,4-stroke,injection
	Rated speed(r/min)	1850
	Rated power(HP/kw)	178/131
	Fuel consumption(g/kw.h)	206
	Max.torque(Nm)	830
Speed	1st	2nd	3rd
Forward(Km/h)	0-3.29	0-5.28	0-9.63
Reverse(Km/h)	0-4.28	0-7.59	0-12.53
Blade type	Straight-tilt	Angle tilt	U-blade
Weight(kg)	17000	17500	17200
Min. ground clearance(mm)	400	400	400
Ground pressure(MPa)	0.067	0.067	0.067
Min. turning radius(m)	4.7	4.4	4.9
Grade ability(°)	30	30	30
Track gauge(mm)	1880	1880	1880
Blade capacity(m^3)	4.5	4.4	5
Blade width(mm)	3388	3970	3556
Blade height(mm)	1149	1090	1120
Max. drop below ground(mm)	530	540	530
Max. tilt adjustment(mm)	400	⁄	400
Drive system	Torque converter	3-element,1-stage,1-phase
	Transmission	Planetary gear type power-shift, forced lubrication
	Main drive	Spiral bevel gear, single-stage reduction ,splash lubrication
	Steering clutch	Wet type, multi-disc, spring loaded, hand-hydraulically separated ,inter-linking with steering brake
	Steering brake	Wet type, banding structure ,foot brake with hydraulic booster
	Final drive	2-stage speed reduction of spur gear, splash lubrication
Undercarriage system	type	Complete frame driving system, 3-point type, suspended structure of equalizer
	Carrier roller	2/each side
	Track roller	6/each side
	Track roller	6/each side
	Track type	Single-tooth
	Width of track shoe(mm)	510
	Pitch(mm)	203.2
