2015 Top sale reliable quality alfalfa granulating machine
This kind duck feed pellet mills is widely used to produce feed pellets for many kinds animals, for example, cattle, carp, chicken, sheep, pig, horse, and other poultry and livestock animal. The pellets by our machine have firm and smooth structure and to digest.
1)Main engine drives with high precision gear, ring die in quick detaching encircling hoop type, output higher 20% than belt drive.
2)Equipped with steam automatic regulatory system to keep refining temperature constant.
3)The complete machine transmission parts include electric motor with Switzerland “SKF” high quality bearing; ensure high –efficiency, stable and low noise drive.
4)Larger type strengthen feeding conditioner in entire stainless steel with frequency speed control, ensure the high quality of pellet feed.
5)Adopt international advanced ring die processed by heat treatment vacuum furnace, lengthen useful life and pellet is smooth with high quality.
6)International advanced level compensated serpentine spring coupling, novel and compact structure, safe, low noise and low machinery failure.
7)Adopt international advanced piping system and import pressure regulating value.
8)With full stainless steel door, flume, and pull cutter which is convenient, reliable.
9)Permanent magnet device with high performance.
10)Customize pellet mill with double layers or three layers.
alfalfa lucerne pelletizer
Model |
SZLH25 |
SZLH32 |
SZLH35 |
SZLH40 |
SZLH420 |
SZLH508 |
Power of main motor(kw) |
22 |
37 |
55 |
90 |
110 |
160 |
Power of conditioner(kw) |
1.5 |
2.2 |
2.2 |
3 |
5.5 |
7.5 |
Yield(t/h) |
1~2 |
2~4 |
2~6 |
3~8 |
4~12 |
4~18 |
Diameter of ring die(mm) |
250 |
320 |
350 |
400 |
450 |
508 |
Feeder power(kw) |
0.75 |
1.5 |
1.5 |
1.5 |
1.5 |
2.2 |
Size of finished pellets(mm) |
1.5~12 |
1.5~12 |
1.5~12 |
1.5~18 |
1.5~18 |
2~18 |
Note:
1.For pig, the pellet diameter is usually ø3.5-6.5mm.
2.For cattle, the pellet diameter is usually ø4.5-8mm.
3.For chicken, pellet diameter is usually ø3.2mm.
4.For fish, pellet diameter is usuallyø2.0, ø2.5, ø3.0mm.
5.For shrimps, pellet diameter is usually ø1.0-ø3.5mm.
Technical data for complete animal feed pellet production line:
Model SZLH25 lucerne pelletizer:
Model SZLH 32 pellet mill:
Model SZLH508 pellet press:
Final Pellets:
[Step 1] Send a inquiry by email or trademanager in below.
[Step 2] We proivide you competitive offer for quality product.
[Step 3] Confirm delivery time and freight operation.
[Step 4] Arrange production after 30% deposit received by T/T.
[Step 5] Confirm consignee and notify party information.
[Step 6] Balance payment received and book ship arranges shipping.
[Step 7] Commercial invoice, packing list and bill of lading sent to you.
[Step 8] Product received. Spare parts can be offered all life.
12 months warranty except for wear parts
broken spare parts (except for wear parts) will be sent for free due to quality problems
Accessories can be offered in the whole life service.
In time response to customers technical problems
New products update for customers' reference
Good quality, mature technology, competitive price and good after-sales service!
If you want a competitive price and more details, pls kindly contact us, we will try our best to satisfy you!
