Functional wood crusher grind machine for sale
Introduction of crusher for wood
* High efficiency wood crusher (sawdust machine, sawdust particle machine) is
the specialized facility for wood crushing, it is developed according to the need
of industrial production.
* Used abroad:it can smash Chinese Herbs,wood chips, slab,bark and all kinds
of straw.
* The final products can be used as raw materials of high density board, small
flake board,paper mill,the material edible mushrooms or charcoal making etc.
Advantages of wood crusher
* Low noise
* Low processing costs
* Chipping and crushing as a whole intergration
* Reasonable design, compact structure, safety, durability, high efficiency.
* Convenient maintenance and movement
Working Principle
* It adopts blade cutting, high speed airflow and double crashing to crush, also
accomplish material sorting processing. In the process of crushing, the rotor
generates strong airflow,with the same direction of blade cutting, materials
can be smashed forcefully.
* The machine is composed of cutting installation, crushing installation and air
blower.
Different view of wood crusher
Specification of wood crusher
TECHINICAL PARAMETER | ||||
Model |
GD500 |
GD600 |
GD800 |
GD1000 |
Dia. of blade (mm) |
500 |
600 |
800 |
1000 |
Qty of crushing blade (pcs) |
12 |
32 |
42 |
52 |
Qty of chipping blade (pcs) |
4 |
3 |
4 |
4 |
Length of blade (mm) |
120 |
200 |
240 |
340 |
Dia. of oblique feeding port (mm) |
150×160 |
160×180 |
200×220 |
330X320 |
Rotating speed (r/m) |
1400 |
1400 |
1200 |
1000 |
Motor power (kw) |
15 |
18.5-22 |
37-45 |
55-75 |
Capacity (kg/h) |
200-300 |
300-1000 |
1000-2000 |
2000-3000 |
Weight (kg) |
300 |
800 |
1400 |
2200 |
Dimension (L*W*H) (mm) |
1200*700*730 |
1300*980*730 |
2000*1000*1300 |
2300*1750*2300 |
More pictures of wood crusher
The sieve of wood crusher
* Standard export packing: wooden case or container
* Within 15-20 working days after deposit
How to order?
1. Send a inquiry by email or Trademanager;
2. We provide you the offer;
3. Confirm delivery time and freight operation;
4. Arrange production after 30% deposit received by T/T
5. Confirm consignee and notify party information.
6. Balance payment received and book ship arranges shipping.
7. Performa invoice, packing list and copy bill of lading sent to you.
8. Product received.
After-sale service
1. Guide customers to choose the best suitable machine model, offer
detailed specification and competitive prices;
2. 12 months warranty except for wear parts;
3. CE , ISO approved, meet with European standard.
4. Broken spare parts (except for wear parts) will be sent for free due
to quality problems.
Henan Guangda is a professional manufacturer and supplier of farm machinery and biomass pellet production line, has been engaging in the international trading for 14 years,
12-180hp wheel tractor, agricultural implements and biomass pellet machine are our main products, widely exported to America, Europe, Africa, Southeast Asia, with high quality standard, rigorous management measures and advanced technology, we have built up very fine reputation at home and abroad.
