Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > Metal Working Machine Small Cantilever Type Cnc Working Tables

Metal Working Machine Small Cantilever Type Cnc Working Tables

Name: Metal Working Machine Small Cantilever Type Cnc Working Tables
Brand: ORANGEMECH
SKU: 139035663
Availability: InStock

Metal Working Machine Small Cantilever Type Cnc Working Tables thumbnail-1

Metal Working Machine Small Cantilever Type Cnc Working Tables photo-1

US$ 1,000 - 3,000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Henan, China

Brand Name:

ORANGEMECH

Contact Supplier Request Quote Chat Now

Luohe Orange Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China main port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Henan, China

Brand Name ORANGEMECH

Model Number OR-XB-1635

Voltage 220v, 220±10%VAC 50/60Hz 220W

Certification ISO

Warranty ONE YEAR

After-sales Service Provided Engineers available to service machinery overseas

Specifications

High Quality Metal Working Machine
1. CE,FDA certificate
2. Oversea after-sale service
3. one year warranty

High Quality Metal Working Machine

Introduction of cantilever type cnc cutting machine:

OR-XB series Cantilever type CNC flame and plasma cutting machine is a kind of high efficiency,energy conservation cutting equipment.It is suitable for all kinds of mild steel,stainless steel and nonferrous metal.With automatic ignition and electric height adjusting device,can move,same as the gub,it is very convenience.

Main Characteristic of cantilever type cnc cutting machine:

1. Running gear adopt the gapless gear, rack drive,the motor is the stepping motor

2. The longitudinal guide rail is the Imported linear guide ,high precision,smooth operation

3. Baseplate is the stainless steel,rust resistant,beautiful and clean

4.Crossbeam adopt the special aluminium alloy material,light weight,Non-deformation

5. Adopt beijing sadafeng control system(with Chinese and English interface),easy operation,leading in the drawing with U disk,can cut directly,do not need programme

6.It can realize simple nesting,automatic compositor,can save the time and material,and also save the cutting torch and consumables

7.Shapes:Can cut any shapes steel plate with line and arc

8. Installation:multiple installation

Technical parameter of cantilever type cnc cutting Machine:

Parameter/Model	OR-XB-1635	OR-XB-2030
Track Guage(mm)	2000	2400
Track length(mm)	4200	4000
Effective Cutting Width(mm)	1650	2000
Effective Cutting Length(mm)	3500	2500
Numbers of Cutting Torch(Group)	1	1
Cutting Thickness(mm)	6-200mm	6-200mm
Cutting Speed(mm/min)	10-3500	10-3500
Control System	Beijing Sida peak SF-2012AH/QG	Beijing Sida peak SF-2012AH/QG
Driving System	Stepper motor	Stepper motor
capacitance automatic vertical steering system	Optional	Optional
Electric height adjusting system	1	1
Automatic ignition device	1	1
Track	Elevator rail	Elevator rail
Drive system	unilateral	unilateral
Gas medium	Oxygen/Ethyne [propane]	Oxygen/Ethyne [propane]
Upgrade for Control System	Free	Free
Harshness cutting surface	Ra12.5	Ra12.5
Accuracy of repetition	±0.5mm	±0.5mm
Oxygen	P=1MPa	P=1MPa
Ethyne	P=0.1MPa	P=0.1MPa
Voltage	AC220v±10%	AC220v±10%
Frequency	50Hz	50Hz
Plasma Power Source	Optional	Optional
Arc voltage automatic height adjusting device	Optional	Optional
Plasma anti-collision device	Optional	Optional
