Mini Dozer SHANTUI Dozer SD16F Forest Dozer

Name: Mini Dozer SHANTUI Dozer SD16F Forest Dozer
Brand: shantui dozer
SKU: 139008631
Availability: InStock

US$ 90,000 - 100,000 MOQ: 1 Unit

Key Specifications

Brand Name:

shantui dozer

Model Number:

SD16F forest dozer

Condition:

New

Qingzhou Bocheng Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao Port China

Delivery Detail:

Delivery time depends on order quantity.

Brand Name shantui dozer

Model Number SD16F forest dozer

Condition New

Moving Type Crawler Bulldozer

Machine Weight 17500kg

Dimension(Long * Breadth * High) 5345*3388*3032mm

After-sales Service Provided Overseas service center available

ITEM	UNIT	SD16F
L×W×H (Ripper not included)	mm	534533883032
Operating weight (Ripper not included)	t	17.5
Engine	-	Shangchai SC11CB184G2B1/ Weichai WD10G178E25
Rated power	kW/rpm	120/1850
Gradeability	°	30
Blade type	-	Straight tilt blade U blade Angle blade
Blade width	mm	Straight tilt blade 3388×1149 U blade 3556×1120 Angle blade 3970×1040
Dozing capacity	m3	Straight tilt blade 4.5 U blade 5 Angle blade 4.3
Ma× drop below ground of blade	mm	540
Lift height of blade	mm	1095
Ripper type	-	Three-shank ripper
Ripping depth of ripper	mm	572
Lifting height of ripper	mm	592
Number of carriers (each side)	-	2
Number of track rollers (each side)	-	7
Number of track shoes (each side)	-	39
Width of track shoe	mm	560
Track gauge	mm	1880
Ground length and ground pressure	mm/MPa	2635-0.062
Pitch	mm	203.2
Forward speed	km/h	0–3.29
		0–5.82
		0–9.63
Reverse speed	km/h	0–4.28
Reverse speed	km/h	0–7.59
