Help CenterWQ Submersiblr Sewage Pump
Related Products
-
WQ/QW Non-clog Sewage PumpUS$ 100 - 1,000MOQ: 1 Set -
High Quality JGGC Series Marine Vertical Centrifugal PumpsUS$ 200 - 650MOQ: 1 Set
-
CS Series Marine Hand PumpUS$ 200 - 650MOQ: 1 Set
-
CPJ-1 Series Marine Injection Water PumpUS$ 200 - 650MOQ: 1 Set
-
CQX Series Marine Sludge Discharge PumpUS$ 200 - 650MOQ: 1 Set
Our factory specializes in producing high efficiency energy-saving sewage pump, high power energy-saving magnetic pump, high temperature and high pressure chemical pump, full automatic constant pressure/flow stainless steel marine pump etc good quality.
Operating Conditions:
1) Capacity scope:5-4500 m³/h;
2) System pressure: ≤1.6mpa;
3) Head scope: 5-75m;
4) Medium Pressure: -15°C~+60°C;
5) Caliber: 50-600mm;
6) Voltage: 380V, 660V;
7) Power: 0.75-315KW.
Main Features:
1. Hydraulic design with wide flow-path non clogged structure, allowed fibers (3 times length of inlet dismeter), particles(30% size of inlet diameter );
2. Excellent design,high efficiency and energy saving ;
3. Double mechnical seals in series,made of hard alloy corrosive proof tungsten carbide,which is durable and .wearable ,that enable pump safely operation for more than 8000 hours continous;
4. Compact structure, small volume, easy moved and conveniently mounted , no need build pump house, greatly reduct the cost;
5. Sensor inside the oil house ensure pump operation at well condition,when mechnical seal broken and water
come into oil house,it will send out signal and protect the pump automatically;
6. Double guide rail self coulped system,makes much convenient for repairing,people no need to get in and out of the sewage pool;
7. Pump with out cooling jack can make sure pump operation at dry condition or dry performance;
8. installing way: Hose Movable Installation / Auto-coupling Installation;
9. Control panel and float switch are available to pump if required.
Structure:
| NO. | Name | NO. | Name |
| 1 | Signal Wire | 9 | Oil House |
| 2 | Cable | 10 | Oil Water Probe |
| 3 | Junction Box | 11 | Mechnical Seal |
| 4 | Motor Box | 12 | Rear Cover |
| 5 | Pump Bearing | 13 | Impeller |
| 6 | Motor Housing | 14 | Pump Body |
| 7 | Stator | 15 | Stirring Wheel |
| 8 | Rotator | 16 | Base |
Main Application:
1) Living waste water discharging;
2) Sewage systems of municipal works;
3) Sewage systems in factory and mine corporation
4) Other transportation of non-corrosive and diluted medium;
5) Temporary floodwater discharging ;
6) Waste water discharging of public facility;
7) Various watered is charging system.
Our Certification:
Our CE and CCC Certificate
Details:
Please feel free to contact us anytime, it's our honor to service for you. We are together!
