Our factory specializes in producing high efficiency energy-saving sewage pump, high power energy-saving magnetic pump, high temperature and high pressure chemical pump, full automatic constant pressure/flow stainless steel marine pump etc good quality.
Operating Conditions:
1) Capacity scope:5-4500 m³/h;
2) System pressure: ≤1.6mpa;
3) Head scope: 5-75m, the pump must be used within the scope of head,ensure that the motor is not overloaded;
4) Medium Pressure: -15°C~+60°C;
5) Caliber: 50-600mm;
6) Voltage: 380V, 660V, it can customized according to customers' requirements;
7) Power: 0.75-315KW;
8) 8) No more of 1/2 part of motor should be exposed.
Main Features:
1. Motor: 100% copper wire, full power;
2. Mechanical seal: alloy and silicon carbide;
3. Shaft:stainless steel;
4. Screw: stainless steel;
5. Outlook: smooth and nice.
Structure:
| NO. | Name | NO. | Name |
| 1 | Signal Wire | 9 | Oil House |
| 2 | Cable | 10 | Oil Water Probe |
| 3 | Junction Box | 11 | Mechnical Seal |
| 4 | Motor Box | 12 | Rear Cover |
| 5 | Pump Bearing | 13 | Impeller |
| 6 | Motor Housing | 14 | Pump Body |
| 7 | Stator | 15 | Stirring Wheel |
| 8 | Rotator | 16 | Base |
Main Application:
1) Living waste water discharging;
2) Sewage systems of municipal works;
3) Sewage systems in factory and mine corporation
4) Other transportation of non-corrosive and diluted medium;
5) Temporary floodwater discharging ;
6) Waste water discharging of public facility;
7) Various watered is charging system.
Our Certification:
Our CE and CCC Certificate
Details:
Please feel free to contact us anytime, it's our honor to service for you. We are together!
