CIS Single-stage and Single-suction Centrifugal Pumps With Good Price

FOB Price

US$ 200 - 650 / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	ZJNM
Model Number	CIS	Theory	Centrifugal Pump
Structure	Other, single-stage and single-suction	Usage	Water
Power	Electric	Standard or Nonstandard	Standard
Fuel	Other, electric	Pressure	Other
Application	Other, water supply

Product Description

CIS single-stage and single-suction centrifugal pumps with good price

General:

CIS Series mqrine horizontal centrifugal pump is widely used for transfer of freshwater, seawater. The pumps are applicable to fire control, cooling and sanitation and applied to industries, to city water supply and drain, and also to agricultural and orchard irrigation.CIR Series pump shall be used for circulation of hot water. When used to pump hot water not higher than 150℃.The Performance parameters and installation dimensions of CIR Series pumps are the same as CI Series pumps.The pump rotates clockwise viewed from motor.

Main technical parameter:

Type	Speed r/min	Capacity m3/h	Head m	Motor power kw	(NPSH)r m	Weight kg	Type	Speed r/min	Capacity m3/h	Head m	Motor power kw
CIS50-32-125	2900	7.5	22	2.2	2	29	CIS65-50-125	2900	15	21.8	3
		12.5	20		2				25	20
		15	18.5		2.5				30	18.5
	1450	3.75	5.4	0.55	2			1450	7.5	5.35	0.55
		6.3	5		2				12.5	5
		7.5	4.6		2.5				15	4.7
CIS50-32-125A	2900	11	15	1.5	2		CIS65-50-125A	2900	22	15	2.2
CIS50-32-125A	1450	5.5	3.7	0.55	2		CIS65-50-125A	1450	11	3.7	5.5
CIS50-32-160	2900	7.5	34.3	3	2	40	CIS65-50-160	2900	15	34	4
		12.5	32		2				25	32
		15	29.6		2.5				30	31
CIS50-32-160	1450	3.75	8.5	0.55	2	40	CIS65-50-160	1450	7.5	8.5	0.75
		6.3	8		2				12.5	8
		7.5	7.5		2.5				15	7.2
CIS50-32-160A	2900	11	24	3	2		CIS65-50-160A	2900	22	24	3
CIS50-32-160A	1450	5.5	6	0.55	2		CIS65-50-160A	1450	11	6	0.55
CIS50-32-200	2900	7.5	52.5	5.5	2	45	CIS65-40-200	2900	15	53	7.5
		12.5	50		2				25	50
		15	48		2.5				30	47
	1450	3.75	13.1	0.75	2			1450	7.5	13.2	1.1
		6.3	12.5		2				12.5	12.5
		7.5	12		2.5				15	11.8
CIS50-32-200A	2900	11	38	4	2		CIS65-40-200A	2900	22	38	5.5
CIS50-32-200A	1450	5.5	9.5	0.55	2		CIS65-40-200A	1450	11	9.5	0.75
CIS50-32-250	2900	7.5	82	11	2	79	CIS65-40-250	2900	15	82	15
		12.5	80		2				25	80
		15	78.5		2.5				30	78
	1450	3.75	20.5	1.5	2			1450	7.5	21	2.2
		6.3	20		2				12.5	20
		7.5	19.5		3				15	19.4
CIS50-32-250A	2900	11	61	7.5	2		CIS65-40-250A	2900	22	61	11
CIS50-32-250A	1450	5.5	15.3	1.1	2		CIS65-40-250A	1450	11	15.3	1.5
CIS65-40-315	2900	15	127	30	2.5	90	CIS80-50-250	2900	30	84	22
		25	125		2.5				50	80
		30	123		3				60	75
	1450	7.5	32.3	4	2.5			1450	15	21	3
		12.5	32		2.5				25	20
		15	31.7		3				30	18.8
CIS65-40-315A	2900	22	97	22	2.5		CIS80-50-250A	2900	45	61	18.5
CIS65-40-315A	1450	11	24	3	2.5		CIS80-50-250A	1450	22	15.3	2.2
CIS50-32-125	2900	7.5	22	2.2	2	29	CIS65-50-125	2900	15	21.8	3
		12.5	20		2				25	20
		15	18.5		2.5				30	18.5
	1450	3.75	5.4	0.55	2			1450	7.5	5.35	0.55
		6.3	5		2				12.5	5
		7.5	4.6		2.5				15	4.7
CIS50-32-125A	2900	11	15	1.5	2		CIS65-50-125A	2900	22	15	2.2
CIS50-32-125A	1450	5.5	3.7	0.55	2		CIS65-50-125A	1450	11	3.7	5.5
CIS50-32-160	2900	7.5	34.3	3	2	40	CIS65-50-160	2900	15	34	4
		12.5	32		2				25	32
		15	29.6		2.5				30	31
CIS50-32-160	1450	3.75	8.5	0.55	2	40	CIS65-50-160	1450	7.5	8.5	0.75
