Help CenterFront End Loader TZ06
Related Products
Specifications
1. front end loader TZ062.with quick hitch
3.match farm tractor :50hp-60hp tractor
FEATURES
· Standard level lift.
· Perfect painting and finishing in details.
· Special requests on the the size of bucket are available
· Quick release bracket and it is very easy for installation.
· Quick release attachment which can work with others Extensive implements
· 4 in 1 bucket, pallet fork and wood Grapple are available on it.
FRONT END LOADER SERIES MAIN SPECIFICATIONS | ||||||||
Front End Loader Model |
TZ03A/BC/D |
TZ04A/B/C/D |
TZ04A/B/C/D |
TZ06A/B/C/D |
TZ08A/B/C/D |
TZ10A/B/C/D |
TZ12A/B/C/D |
|
Matching Tractor |
Kw(hp) |
14.7-22.1(20-30) |
22.1-29.4(30-40) |
29.4-36.8(40-50) |
36.8-44.1(50-60) |
44.1-58.8(60-80) |
58.8-66.2(80-90) |
88.2-102.9(120-140) |
Rated Lift Capacity |
kg |
300 |
400 |
500 |
600 |
800 |
1000 |
1200 |
Max.Dump height |
mm |
1800 |
2000 |
2100 |
2200 |
2350 |
2350 |
2500 |
Digging Depth |
mm |
100 |
120 |
140 |
140 |
180 |
180 |
200 |
Bucket Capacity |
M3 |
0.18 |
0.3 |
0.35 |
0.4 |
0.48 |
0.6 |
1 |
Dump Angle |
(°) |
42-45 |
42-45 |
42-45 |
42-45 |
42-45 |
42-45 |
42-45 |
Weight |
kg |
470-650 |
500-680 |
530-720 |
660-800 |
680-830 |
800-980 |
960-1150 |
PRODUCT SHOW
PHOTO TAKEN IN THE WORK SITE
