Specifications
1. front end loader TZ042.with quick hitch
3.match farm tractor 25hp-50hp
FRONT END LOADER:
TZ04 Series Front Loader to suit for farm tractor 254,304,354,404,454,504
Specification&Features&Options:
· Standard level lift.
· Perfect painting and finishing in details.
· Special requests on the the size of bucket are available
· Quick release bracket and it is very easy for installation.
· Quick release attachment which can work with others Extensive implements
· 4 in 1 bucket, pallet fork and wood Grapple are available on it.
Technical Data |
TZ04 |
Max. Lift Height – Measured at Pivot Pin (mm) |
2400 |
Max. Lift height – Under Level Bucket (mm) |
2000 |
Max. Dump reach (mm) |
800 |
Dump angle (°) |
42 |
Reach with Bucket on Ground (mm) |
1830 |
Rollback angle on ground (°) |
26 |
Max. Digging depth (mm) |
100 |
Rated load (kg) |
360 |
Bucket Capacity (m3) |
0.3 |
Pallet Fork Length(mm) |
1030 |
Pallet Fork Width(mm) |
960 |
Pallet Fork Load(kg) |
360 |
Wood Grapple Width(mm) |
960 |
Wood Diameter/Weight(mm)/(kg) |
800/360 |
Recommended Tractor HP |
35-50 |
