Hot Sale Excavator

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

CT330-8C

Weifang Fumei Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name FM

Model Number CT330-8C

Condition New

Moving Type Crawler Excavator

Operating Weight 32000kg

Bucket capacity 1.4CBM

Maximum Digging Height 10078MM

Maximum Digging Depth 6460MM

Machine Weight 32000kg

Rated Speed 5.0/3.1km/h

Certification CE

After-sales Service Provided No overseas service provided

Specifications

1)Original ISUZU 6BG1TRP-01
2)Kawasaki pump,Parker valve
3)1.4CBM bucket
4)Operating weight:32000kg
5)A/C

Excavator model	CT330-8C with cabin
Specification of CT330-8c with cabin
Operate weight kg		32000
Bucket capacity M3		1.4
Engine model		ISUZU 6BG1TRP-01
Engine power (kw)		184kw/2000rpm
Swing spreed (rpm)		10
Ground pressure (Kpa)		59.6
Travel speed (km/h)		5.0/3.1
Gradeability (°)		30
Bucket digging force (KN)		227
Fuel tank capacity(L)		630
Hydraulic tank capacity(L)		260
Main dimensions
Upperstrcuture witdth (mm)		3195
Undercarriage width (mm)		3190
Cabinet hight (mm)		3125
Rear swing radius (mm)		3425
Ground clearance (mm)		500
Working range
Max.digging reach (mm)		11077
Max.digging depth (mm)		7362
Max.digging height (mm)		10078
Max.dumping height (mm)		7382
Max.vertical wall digging depth (mm)		6460
Min,swing radius (mm)		4348
Standard Equipment
Japanese Kawasaki main pump , swing motor
Japanese KYB valve, traveling motor
Italian pilot control lever

Warranty,Payment and Delivery
Warranty Term: 1200 working hours or 1 year, whichever come first
Payment Term: 100% T/T or Irrevocable L/C payable at sight
Time of delivery: 30 days for models with standard equipment, after receipt of L/C or 30% T/T down payment.
