Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > 36ton Excavator CT360-8C CE Certificate,construction Machine

36ton Excavator CT360-8C CE Certificate,construction Machine

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

CT360-8C

Weifang Fumei Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name CT

Model Number CT360-8C

Condition New

Moving Type Crawler Excavator

Operating Weight 33000KG

Bucket capacity 1.4CBM

Maximum Digging Height 10078mm

Maximum Digging Depth 7362mm

Machine Weight 33000kg

Max Digging Radius 11077mm

Rated Speed 5.0/3.1

Certification CE

After-sales Service Provided Overseas third-party support available

Specifications

1.crawler excavator CT360-8C
2.engine:ISUZU 6BG1TRP-01
3.rated power:184KW
4.bucket capacity:1.4CBM
5.Japanese Kawasaki main

Specification of CT360-8C excavator with cabin

CT360-8c
Operate weight kg	33000
Bucket capacity M3	1.4
Engine model	ISUZU 6BG1TRP-01
Engine power (kw)	184kw/2000rpm
Swing spreed (rpm)	10
Ground pressure (Kpa)	65.3
Travel speed (km/h)	5.0/3.1
Gradeability (°)	50
Bucket digging force (KN)	259
Fuel tank capacity(L)	630
Hydraulic tank capacity(L)	260
Main dimensions
Upperstrcuture witdth (mm)	3195
Undercarriage width (mm)	3190
Cabinet hight (mm)	3125
Rear swing radius (mm)	3425
Ground clearance (mm)	500
Working range
Max.digging reach (mm)	11077
Max.digging depth (mm)	7362
Max.digging height (mm)	10078
Max.dumping height (mm)	7382
Max.vertical wall digging depth (mm)	6460
Min,swing radius (mm)	4348
Standard Equipment
Japanese Kawasaki main pump
Japanese KYB valve,tracking motor
Italian valve ,pilot control lever
